ASRock EC262D4U-2L2T - Micro-ATX LGA1700 Server Motherboard, DDR5 ECC, 4x DIMM, 8x SATA, 1x M.2, 4x LAN
ASRock EC262D4U-2L2T micro-ATX server board for LGA1700 Intel Xeon, DDR5 ECC support, 4 DIMM slots, PCIe 5.0 x16, 1x M.2, 8x SATA III, 4x RJ-45, VGA & COM
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| Motherboards - Socket | LGA1700 |
|---|---|
| Motherboards - Form Factor | Micro-ATX |
| Motherboards - Memory Type | DDR5 |
| Motherboards - Memory Slots | 4 |
| Motherboards - PCIe Version (primary GPU) | PCIe 5.0 |
| Motherboards - M.2 Slots | 1 |
| Motherboards - SATA Ports | 8 |
Asrock EC262D4U-2L2T. Processor manufacturer: Intel. Processor socket: LGA 1700. Compatible processor series: Intel® Xeon®. Supported memory types: DDR5-SDRAM. Memory slots type: DIMM. Memory voltage: 1.1 V. Supported storage drive interfaces: M.2. RAID levels: 0. 1. 5. 10. Motherboard form factor: micro ATX. Motherboard chipset family: Intel. Motherboard chipset: Intel C262. BIOS type: AMI. BIOS memory size: 256 Mbit
| Processor manufacturer | Intel |
| Processor socket | LGA 1700 |
| Compatible processor series | Intel® Xeon® |
| Supported processor sockets | LGA 1700 |
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Memory voltage | 1.1 V |
| ECC сompatibility | ECC |
| Supported storage drive interfaces | M.2 |
| Feature | Ethernet LAN |
| RAID levels | 0. 1. 5. 10 |
| USB 2.0 connectors | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Number of SATA III connectors | 8 |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 4 |
| VGA (D-Sub) ports quantity | 1 |
| COM ports quantity | 1 |
| Motherboard chipset | Intel C262 |
| PC health monitoring | CPU. Fan |
| Motherboard form factor | micro ATX |
| Motherboard chipset family | Intel |
| PCI Express x1 (Gen 4.x) slots | 1 |
| PCI Express x4 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| Number of M.2 (M) slots | 1 |
| BIOS type | AMI |
| BIOS memory size | 256 Mbit |
| ACPI version | 6.4 |
| System Management BIOS (SMBIOS) version | 2.8 |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Width | 244 mm |
| Depth | 244 mm |
