EATON USV 5SC 700 700VA 525Watt Line interactive US-Modell 120V (US)
Eaton 5SC750, 0,75 kVA, 525 W, Sine, 96 V, 144 V, 50/60 Hz
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Eaton 5SC750. Ausgangskapazität: 0,75 kVA, Ausgangsleistung: 525 W, Wellenform: Sine. AC-Steckertypen: NEMA 5–15R, Stecker: NEMA 5-15P, Anzahl der AC-Ausgänge: 6 AC-Ausgänge. Akku-/Batterietechnologie: Plombierte Bleisäure (VRLA), Typische Backup-Zeit bei voller Belastung: 5 min, Typische Backup-Zeit bei halber Belastung: 13 min. Formfaktor: Tower, Produktfarbe: Schwarz, Kabellänge: 1,8 m. Konformitätsbescheinigungen: RoHS, Zertifizierung: IEC 62040-2:2006 Cat C2 / CISPR22 Class A / FCC part 15 Class A
| Ausgangskapazität | 0,75 kVA |
| Ausgangsleistung | 525 W |
| Wellenform | Sine |
| Eingangs-Betriebsspannung (min) | 96 V |
| Eingangs-Betriebsspannung (max) | 144 V |
| Eingangsfrequenz | 50/60 Hz |
| Effizienz | 94% |
| Geräuschpegel | 55 dB |
| AC-Steckertypen | NEMA 5–15R |
| Stecker | NEMA 5-15P |
| Anzahl der AC-Ausgänge | 6 AC-Ausgänge |
| Anzahl USB 2.0 Anschlüsse | 1 |
| RS-232 port | 1 |
| Akku-/Batterietechnologie | Plombierte Bleisäure (VRLA) |
| Typische Backup-Zeit bei voller Belastung | 5 min |
| Typische Backup-Zeit bei halber Belastung | 13 min |
| Kaltstart | Ja |
| Formfaktor | Tower |
| Kabellänge | 1,8 m |
| Produktfarbe | Schwarz |
| Display-Typ | LCD |
| LED-Anzeigen | Ja |
| Betriebstemperatur | 0 - 35 °C |
| Temperaturbereich bei Lagerung | 0 - 40 °C |
| Relative Luftfeuchtigkeit in Betrieb | 0 - 90% |
| Konformitätsbescheinigungen | RoHS |
| Zertifizierung | IEC 62040-2:2006 Cat C2 / CISPR22 Class A / FCC part 15 Class A |
| Sicherheit | CE/cULus/NOM |
| Breite | 150 mm |
| Tiefe | 340 mm |
| Höhe | 209 mm |
| Gewicht | 10,5 kg |
| Warentarifnummer (HS) | 85078000 |
| Nominale Ausgang Spannung | 120 V |
| Nominale Eingang Spannung | 120 V |
