Server System M50CYP2UR312 - Server - Rack-Montage - 2U - keine CPU - RAM 0 GB - SATA-SAS
Intel Server System M50CYP2UR312, Intel C621A, Intel, Intel® Xeon®, DDR4-SDRAM, 12 TB, 2.5"
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Intel Server System M50CYP2UR312. Motherboard Chipsatz: Intel C621A, Prozessorhersteller: Intel, Prozessorfamilie: Intel® Xeon®. Unterstützte Arbeitsspeicher: DDR4-SDRAM, RAM-Speicher maximal: 12 TB. unterstützte Speicherlaufwerksgrößen: 2.5", Unterstützte Speicherlaufwerke: SSD, RAID Level: 0, 1, 5, 10. Eingebautes Grafikkartenmodell: Aspeed AST2500. Exportkontroll-Klassifizierungsnummer (ECCN): 5A002U, Warenklassifizierungssystem zur automatisierten Nachverfolgung (CCATS): G157815L1
| Eingebauter Prozessor | Nein |
| Motherboard Chipsatz | Intel C621A |
| Prozessorhersteller | Intel |
| Prozessorfamilie | Intel® Xeon® |
| Anzahl unterstützter Prozessoren | 2 |
| Zahl der DIMM Slots | 32 |
| Unterstützte Arbeitsspeicher | DDR4-SDRAM |
| RAM-Speicher maximal | 12 TB |
| Anzahl der unterstützten Speicherlaufwerke | 12 |
| HDD Laufwerkschächte Hot-Swap | Ja |
| Anzahl der 2,5" Erweiterungseinschübe | 12 |
| unterstützte Speicherlaufwerksgrößen | 2.5" |
| Unterstützte Speicherlaufwerke | SSD |
| RAID Level | 0, 1, 5, 10 |
| Eingebautes Grafikkartenmodell | Aspeed AST2500 |
| Anzahl der USB-Anschlüsse | 6 |
| Anzahl USB 2.0 Anschlüsse | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A | 4 |
| Anzahl serielle Anschlüsse | 2 |
| SATA Anschlüsse | 10 |
| Anzahl der SAS-Ports | 8 |
| Optisches Laufwerk - Typ | Nein |
| Integrierter BMC mit IPMI | Ja |
| Trusted Platform Module (TPM) | Ja |
| Trusted Platform Module (TPM) Version | 2.0 |
| Exportkontroll-Klassifizierungsnummer (ECCN) | 5A002U |
| Warenklassifizierungssystem zur automatisierten Nachverfolgung (CCATS) | G157815L1 |
| ARK ID | 214841 |
| Warentarifnummer (HS) | 8473301180 |
| Intel® Advanced Management Technology | Ja |
| Intel® Remote Management Module Support | Y |
| Intel® Intel®ligent Power Node Manager | Ja |
| Intel® Virtualisierungstechnik für direkte I/O (VT-d) | Ja |
| Intel® Optane™ Memory-bereit | Ja |
| BIOS-Typ | UEFI |
| Gehäusetyp | Rack (2U) |
| Ablageschienen | Nein |
| ablagefreundliches Bord | Ja |
| Ungenutzter Lüfter-Support | Ja |
| Netzteiltyp | AC |
| Stromversorgung | 2100 W |
| Unterstützung für redundantes Netzteil | Ja |
| Thermal Design Power (TDP) | 270 W |
| Breite | 712 mm |
| Tiefe | 439 mm |
| Höhe | 89 mm |
| CPU Konfiguration (max) | 2 |
| Eingebaute Grafikadapter | Ja |
| Erweiterte Garantie zum Kauf erhältlich (Länder auswählen) | Ja |
| Startdatum | Q2'21 |
| Riser Slot 1 Anzahl der Fahrstreifen | 32 |
| Riser Slot 2 Anzahl der Fahrstreifen | 32 |
| Status | Launched |
| Unterstützte RAID-Konfiguration | 0/1/5/10 |
| Zielmarkt | Mainstream |
| Riser Slot 3 Anzahl der Fahrstreifen | 16 |
