EATON 9PX1000IRT2U
Eaton 9PX1000IRT, Doppelwandler (Online), 1 kVA, 1000 W, Reiner Sinus, 176 V, 276 V
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Eaton 9PX1000IRT. USV-Topologie: Doppelwandler (Online), Ausgangskapazität: 1 kVA, Ausgangsleistung: 1000 W. AC-Steckertypen: C13-Koppler, Stecker: C14-Koppler, Anzahl der AC-Ausgänge: 8 AC-Ausgänge. Akku-/Batterietechnologie: Plombierte Bleisäure (VRLA), Typische Backup-Zeit bei voller Belastung: 6 min, Typische Backup-Zeit bei halber Belastung: 16,5 min. Formfaktor: Rackmount/Tower, Produktfarbe: Schwarz, Rack-Kapazität: 2U. Zertifizierung: IEC/EN 62040-1, UL 1778, CSA 22.2, IEC/EN 62040 -2, FCC Class B, CISPR22 Class B, CE /CB report...
| USV-Topologie | Doppelwandler (Online) |
| Ausgangskapazität | 1 kVA |
| Ausgangsleistung | 1000 W |
| Wellenform | Reiner Sinus |
| Eingangs-Betriebsspannung (min) | 176 V |
| Eingangs-Betriebsspannung (max) | 276 V |
| Eingangsfrequenz | 40/70 Hz |
| Ausgangs-Betriebsspannung (min) | 200 V |
| Ausgangs-Betriebsspannung (max) | 240 V |
| Output Frequenz | 50/60 Hz |
| Anzahl der Eingangs-Phasen | 1 |
| Effizienz | 91,5% |
| Leistungsfaktor | 1 |
| Geräuschpegel | 35 dB |
| Energieschutzeigenschaften | Batterieentladung |
| AC-Steckertypen | C13-Koppler |
| Stecker | C14-Koppler |
| Anzahl der AC-Ausgänge | 8 AC-Ausgänge |
| USB Anschluss | Ja |
| Anzahl USB 2.0 Anschlüsse | 1 |
| Serielle Schnittstelle | RS-232 |
| RS-232 port | 1 |
| Akku-/Batterietechnologie | Plombierte Bleisäure (VRLA) |
| Typische Backup-Zeit bei voller Belastung | 6 min |
| Typische Backup-Zeit bei halber Belastung | 16,5 min |
| Hot-Swap-Batterie | Ja |
| Automatischer Batterietest | Ja |
| Formfaktor | Rackmount/Tower |
| Rack-Kapazität | 2U |
| Produktfarbe | Schwarz |
| Display-Typ | LCD |
| LED-Anzeigen | Ja |
| Betriebstemperatur | 0 - 40 °C |
| Zertifizierung | IEC/EN 62040-1, UL 1778, CSA 22.2, IEC/EN 62040 -2, FCC Class B, CISPR22 Class B, CE /CB report (TUV) / cULus / EAC /RCM / KC / Energy Star |
| Rackmontageset | Ja |
| Management-Karte enthalten | Nein |
| Sicherheit | IEC/EN 62040-1, UL 1778, CSA 22.2 |
| Nachhaltigkeitszertifikate | ENERGY STAR |
| Breite | 440 mm |
| Tiefe | 450 mm |
| Höhe | 86,5 mm |
| Gewicht | 19,5 kg |
| Mitgelieferte Software | Intelligent Power Software suite |
| Warentarifnummer (HS) | 85078000 |
| Nominale Eingang Spannung | 230 V |
