Intel S1700 CORE i7 12700T TRAY 12x1,4 35W GEN12
Intel Core i7-12700T, Intel® Core™ i7, LGA 1700, Einschub, Intel, i7-12700T, 64-Bit
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Intel Core i7-12700T. Prozessorfamilie: Intel® Core™ i7, Prozessorsockel: LGA 1700, Verpackungsart: Einschub. Speicherkanäle: Zweikanalig, Maximaler interner Speicher, vom Prozessor unterstützt: 128 GB, Speichertypen, vom Prozessor unterstützt: DDR4-SDRAM, DDR5-SDRAM. Eingebautes Grafikkartenmodell: Intel UHD Graphics 770, On-Board Grafikadapter unterstützte Ausgänge: Embedded DisplayPort (eDP), Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, DisplayPort 1.4,..., On-Board Grafikadapter Basisfrequenz: 300 MHz. Marktsegment: Desktop, Nutzungsbedingungen: PC/Client/Tablet, Arbeitsstation, PCI-Express-Slots-Version: 5.0, 4.0. Intel® Turbo Boost Max Technology 3.0 frequency: 4,7 GHz
| Prozessorhersteller | Intel |
| Prozessorgeneration | Intel® Core™ i7 Prozessoren der 12. Generation |
| Prozessor | i7-12700T |
| Prozessorfamilie | Intel® Core™ i7 |
| Anzahl Prozessorkerne | 12 |
| Prozessorsockel | LGA 1700 |
| Prozessor-Threads | 20 |
| Prozessorbetriebsmodi | 64-Bit |
| Leistungskerne | 8 |
| Effiziente Kerne | 4 |
| Prozessor Boost-Frequenz | 4,7 GHz |
| Leistung Kern-Boost-Frequenz | 4,6 GHz |
| Leistung Basisfrequenz des Kerns | 1,4 GHz |
| Effiziente Kern-Boost-Frequenz | 3,4 GHz |
| Effiziente Basisfrequenz des Kerns | 1 GHz |
| Prozessor-Cache | 25 MB |
| Prozessor Cache Typ | Smart Cache |
| Verpackungsart | Einschub |
| Grundleistung des Prozessors | 35 W |
| Maximale Turboleistung | 99 W |
| Bus Typ | DMI4 |
| Maximale Anzahl DMI-Spuren | 8 |
| Durch den Prozessor (max) unterstützte Speicherbandbreite | 76,8 GB/s |
| Prozessor Codename | Alder Lake |
| ARK Prozessorerkennung | 134596 |
| Maximaler interner Speicher, vom Prozessor unterstützt | 128 GB |
| Speichertypen, vom Prozessor unterstützt | DDR4-SDRAM, DDR5-SDRAM |
| Speicherkanäle | Zweikanalig |
| ECC | Ja |
| Speicherbandbreite (max.) | 76,8 GB/s |
| Eingebaute Grafikadapter | Ja |
| Separater Grafikadapter | Nein |
| Eingebautes Grafikkartenmodell | Intel UHD Graphics 770 |
| On-Board Grafikadapter unterstützte Ausgänge | Embedded DisplayPort (eDP), Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, DisplayPort 1.4, HDMI 2.1 |
| On-Board Grafikadapter Basisfrequenz | 300 MHz |
| Maximale dynamische Frequenz der On-Board Grafikadapter | 1,5 MHz |
| Anzahl an unterstützen Displays (On-Board-Grafik) | 4 |
| On-Board Grafikadapter DirectX Version | 12.0 |
| On-Board Grafikadapter OpenGL Version | 4.5 |
| Maximale Auflösung des On-Board Grafikadapters (DisplayPort) | 7680 x 4320 Pixel |
| Maximale Auflösung des On-Board Grafikadapters (eDP - integrierter Flachbildschirm) | 5120 x 3200 Pixel |
| Integrierter Grafik-Adapter maximale Auflösung (HDMI) | 4096 x 2160 Pixel |
| Bildwiederholfrequenz des On-Board Grafikadapters bei maximaler Auflösung (DisplayPort) | 60 Hz |
| Bildwiederholfrequenz des On-Board Grafikadapters bei maximaler Auflösung (eDP - integrierter Flachbildschirm) | 120 Hz |
| Bildwiederholfrequenz des On-Board Grafikadapters bei maximaler Auflösung (HDMI) | 60 Hz |
| On-Board Grafikadapter Geräte-ID | 0x4680 |
| Separates Grafikkartenmodell | Nicht verfügbar |
| Anzahl der Rechenwerke | 32 |
| Multi-Format-Codec-Engines | 2 |
| Execute Disable Bit | Ja |
| Leerlauf Zustände | Ja |
| Thermal-Überwachungstechnologien | Ja |
| Marktsegment | Desktop |
| Nutzungsbedingungen | PC/Client/Tablet, Arbeitsstation |
| Maximale Anzahl der PCI-Express-Lanes | 20 |
| PCI-Express-Slots-Version | 5.0, 4.0 |
| PCI Express Konfigurationen | 1x16+1x4, 2x8+1x4 |
| Unterstützte Befehlssätze | SSE4.1, SSE4.2, AVX 2.0 |
| Skalierbarkeit | 1S |
| CPU Konfiguration (max) | 1 |
| Eingebettete Optionen verfügbar | Nein |
| Spezifikation der thermischen Lösung | PCG 2020D |
| Direkte Medienschnittstelle (DMI) Revision | 4.0 |
| Exportkontroll-Klassifizierungsnummer (ECCN) | 5A992.C |
| Warenklassifizierungssystem zur automatisierten Nachverfolgung (CCATS) | G167599 |
| Intel® Hyper-Threading-Technik (Intel® HT Technology) | Ja |
| Intel® Turbo-Boost-Technologie | 2.0 |
| Intel® Quick-Sync-Video-Technik | Ja |
| Intel® Clear Video HD Technology für (Intel® CVT HD) | Ja |
| Intel® AES New Instructions (Intel® AES-NI) | Ja |
| Verbesserte Intel SpeedStep Technologie | Ja |
| Intel® Trusted-Execution-Technik | Ja |
| Intel®-Speed-Shift-Technologie | Ja |
| Intel® Turbo Boost Max Technology 3.0 frequency | 4,7 GHz |
| Intel® Total Memory Encryption | Ja |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Ja |
| Intel® Control-flow Enforcement Technology (CET) | Ja |
| Intel® Thread Director | Ja |
| Intel® Enhanced Halt State | Ja |
| Intel® VT-x mit Extended Page Tables (EPT) | Ja |
| Intel® Sicherer Schlüssel | Ja |
| Intel® Active Management Technologie (Intel® AMT) | Ja |
| Intel Stable Image Platform Program (SIPP) | Ja |
| Intel® OS Guard | Ja |
| Intel® 64 | Ja |
| Intel® Virtualization Technologie (VT-X) | Ja |
| Intel® Virtualisierungstechnik für direkte I/O (VT-d) | Ja |
| Intel Turbo Boost Max Technology 3.0 | Ja |
| Intel® Optane™ Memory-bereit | Ja |
| Intel® Boot Guard | Ja |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Ja |
| Intel® Volume Management Device (VMD) | Ja |
| Modusbasierte Execute Control (MBE) | Ja |
| Intel® vPro™ Platform Eligibility | Ja |
| Intel® Standard Manageability (ISM) | Ja |
| Intel® One-Click Recovery | Ja |
| Intel® Stable IT Platform Program (SIPP) | Ja |
| Intel® Virtualisierungstechnik mit Umleitungsschutz (VT-rp) | Ja |
| Intel vPro® Enterprise Plattform-Berechtigung | Ja |
| Intel® Threat Detection Technology (TDT) | Ja |
| Intel® Hardware Shield Eligibility | Ja |
| Intel® Total Memory Encryption - Multi Key | Ja |
| Intel vPro® Essentials Platform Eligibility | Ja |
| Maximale Betriebstemperatur | 100 °C |
| Tjunction | 100 °C |
| Zielmarkt | Gaming, Content Creation |
| OpenCL-Version | 3.0 |
| Startdatum | Q1'22 |
| OpenGL-Unterstützung | Ja |
| Status | Launched |
| Warentarifnummer (HS) | 85423119 |
| Prozessor-Paketgröße | 45 x 37.5 mm |
| Pufferspeicher L2 | 12288 KB |
| RAM-Speicher maximal | 128 GB |
| Grafischer Ausgang | eDP 1.4b, DP 1.4a, HDMI 2.1 |
