Barebone nano NE10N N100 1x260 PIN SO DIMM
Shuttle Nano PC NE10N, Intel N 100, 1x HDMI, 1x DP, 6x USB, 1x LAN, VESA, lüfterlos, 24/7 Dauerbetrieb, 0,6L Größe PC, Mini-PC Barebone, Intel SoC, DDR4-SDRAM, PCI Express, SATA, 65 W
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Shuttle Nano PC NE10N, Intel N 100, 1x HDMI, 1x DP, 6x USB, 1x LAN, VESA, lüfterlos, 24/7 Dauerbetrieb. Gehäusetyp: 0,6L Größe PC, Produkttyp: Mini-PC Barebone. Motherboard Chipsatz: Intel SoC, BIOS-Typ: EFI AMI. Unterstützte Arbeitsspeicher: DDR4-SDRAM, Anzahl der Speichersteckplätze: 1, RAM-Speicher maximal: 16 GB. Unterstützte Speicherlaufwerke: SSD, Speicherlaufwerk Schnittstelle: PCI Express, SATA. Anzahl Ethernet-LAN-Anschlüsse (RJ-45): 1. Kühlung: Passiv. Stromversorgung: 65 W
| Prozessorhersteller | Intel |
| Prozessor | N100 |
| Anzahl Prozessorkerne | 4 |
| Prozessor-Threads | 4 |
| Prozessor Boost-Frequenz | 3,4 GHz |
| Eingebauter Prozessor | Ja |
| Prozessor-Cache | 6 MB |
| Arbeitsspeicher Typ | SO-DIMM |
| Anzahl der Speichersteckplätze | 1 |
| RAM-Speicher maximal | 16 GB |
| Unterstützte Arbeitsspeichergeschwindigkeit | 3200 MHz |
| Unterstützte Arbeitsspeicher | DDR4-SDRAM |
| Speicherkanäle | Einfach-Kanal |
| Speicherspannung | 1.2 V |
| ECC | Nein |
| Ohne ECC | Ja |
| Unterstützte Speicherlaufwerke | SSD |
| unterstützte Speicherlaufwerksgrößen | M.2 |
| SSD-Formfaktor | M.2 |
| Speicherlaufwerk Schnittstelle | PCI Express, SATA |
| Integrierter Kartenleser | Nein |
| Eingebaute Grafikadapter | Ja |
| Grafikkarte-Familie | Intel |
| Eingebautes Grafikkartenmodell | Intel® UHD Graphics |
| Motherboard Chipsatz | Intel SoC |
| Anzahl unterstützter Prozessoren | 1 |
| BIOS-Typ | EFI AMI |
| Trusted Platform Module (TPM) | Ja |
| Trusted Platform Module (TPM) Version | 2.0 |
| Audio-Chip | Senary SN6141 |
| Eingebaute Lautsprecher | Nein |
| Ethernet/LAN | Ja |
| WLAN | Nein |
| Anzahl USB 2.0 Anschlüsse | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Anschlüsse vom Typ A | 4 |
| Anzahl HDMI-Anschlüsse | 1 |
| HDMI-Version | 2.0 |
| Anzahl DisplayPort Anschlüsse | 1 |
| DisplayPorts-Version | 1.4 |
| Mikrofon-Eingang | Ja |
| Kopfhörerausgänge | 1 |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 1 |
| Gleichstrom-Anschluss (DC) | Ja |
| Gehäusetyp | 0,6L Größe PC |
| Produktfarbe | Schwarz |
| Kühlung | Passiv |
| LED-Anzeigen | Ja |
| Gehäusematerial | Kunststoff |
| Kabelsperre-Slot | Ja |
| Slot-Typ Kabelsperre | Kensington |
| VESA-Halterung | Ja |
| Panel-Montage-Schnittstelle | 75 x 75,100 x 100 mm |
| Produkttyp | Mini-PC Barebone |
| Konformitätsbescheinigungen | BSMI, CE, Eidgenössische Kommunikationskommission (FCC), RCM, RoHS, UKCA, VCCI |
| Warentarifnummer (HS) | 84733080 |
| Unterstützt Windows-Betriebssysteme | Windows 11 |
| Unterstützte Linux-Betriebssysteme | Ja |
| Nachhaltigkeitszertifikate | ENERGY STAR, ErP |
| Netzteiltyp | Externer AC-Adapter |
| Stromversorgung | 65 W |
| Anzahl von Stromversorgungseinheiten | 1 |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| Netzteil Ausgangsspannung | 19 V |
| AC-Adapter Ausgangssstrom | 3,42 A |
| Betriebstemperatur | 0 - 40 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Breite | 135 mm |
| Tiefe | 115 mm |
| Höhe | 39 mm |
| Gewicht | 600 g |
| Paketgewicht | 1,5 kg |
| Netzkabel enthalten | Ja |
| AC-Netzadapter | Ja |
| Schnellstartübersicht | Ja |
| Treiber enthalten | Ja |
