ASROCK H810M-P GEN5 DDR5 Intel S1851 90-MXBUE0-A0UAYZ retail
Asrock H810M-P Gen5, Intel, LGA 1851 (Socket V1), Intel Core Ultra (Series 2), DDR5-SDRAM, 128 GB, DIMM
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Asrock H810M-P Gen5. Prozessorhersteller: Intel, Prozessorsockel: LGA 1851 (Socket V1), Kompatible Prozessoren: Intel Core Ultra (Series 2). Unterstützte Arbeitsspeicher: DDR5-SDRAM, RAM-Speicher maximal: 128 GB, Arbeitsspeicher Typ: DIMM. Unterstützte Speicherlaufwerk-Schnittstellen: SATA III, M.2, Unterstützte Speicherlaufwerke: HDD & SSD. LAN-Controller: Realtek RTL8111H. Komponente für: PC, Motherboardformfaktor: micro ATX, Motherboard Chipsatz Familie: Intel
| Prozessorhersteller | Intel |
| Prozessorsockel | LGA 1851 (Socket V1) |
| Kompatible Prozessoren | Intel Core Ultra (Series 2) |
| Maximale Anzahl an SMP-Prozessoren | 1 |
| Unterstützte Arbeitsspeicher | DDR5-SDRAM |
| Anzahl der Speichersteckplätze | 2 |
| Arbeitsspeicher Typ | DIMM |
| Speicherkanäle | Zweikanalig |
| ECC-Kompatibilität | Nicht-ECC |
| RAM-Speicher maximal | 128 GB |
| Unbuffered Speicher | Ja |
| Unterstützte Speicherlaufwerke | HDD & SSD |
| Unterstützte Speicherlaufwerk-Schnittstellen | SATA III, M.2 |
| HDCP | Ja |
| HDCP-Version | 2.3 |
| Anzahl USB 2.0 Schnittstellen | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anschlüsse | 1 |
| SATA III Anschlüsse | 4 |
| Front Panel Audiostecker | Ja |
| ATX Stromstecker (24-pol.) | Ja |
| CPU Ventilatorstecker | Ja |
| Anzahl der CPU-Lüfteranschlüsse | 1 |
| Zahl der Chassisventilatorstecker | 1 |
| EPS Stromstecker (8-pin) | Ja |
| Anzahl der EPS-Stromanschlüsse (4--polig) | 1 |
| TPM-Anschluss | Ja |
| RGB-LED-Stiftleiste | Ja |
| Anzahl der RGB-LED-Stiftleisten | 2 |
| Anzahl USB 2.0 Anschlüsse | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A | 2 |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 1 |
| Anzahl HDMI-Anschlüsse | 1 |
| Anzahl DisplayPort Anschlüsse | 1 |
| DisplayPorts-Version | 1.4 |
| Line-in | Ja |
| Mikrofon-Eingang | Ja |
| Ethernet/LAN | Ja |
| LAN-Controller | Realtek RTL8111H |
| WLAN | Nein |
| Motherboard Chipsatz | Intel H810 |
| Audio-Chip | Realtek ALC897 |
| Audio Kanäle | 7.1 Kanäle |
| Komponente für | PC |
| Motherboardformfaktor | micro ATX |
| Motherboard Chipsatz Familie | Intel |
| Unterstützt Windows-Betriebssysteme | Windows 11 x64 |
| PCI Express x1-Steckplätze (Gen 4.x) | 1 |
| PCI Express x16-Steckplätze (Gen 5.x) | 1 |
| Anzahl der M.2 (M)-Steckplätze | 1 |
| BIOS-Typ | EFI AMI |
| BIOS-Speichergröße | 256 Mbit |
| Breite | 244 mm |
| Tiefe | 193 mm |
| Mitgelieferte Kabel | SATA |
| Schrauben enthalten | Ja |
