Barebone ShuttleBarebone XPC slim DH610 Black
Shuttle Slim PC DH610 , S1700, 1x HDMI, 2x DP , 1x 2.5" , 2x M.2, 2x LAN (Intel 1G + 2.5G), 2x COM, 24/7 Dauerbetrieb, inkl. VESA, 1,3L Größe PC, Mini-PC Barebone, LGA 1700, DDR4-SDRAM, M.2, SATA, Serial ATA II, Serial ATA III, 120 W
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Shuttle Slim PC DH610 , S1700, 1x HDMI, 2x DP , 1x 2.5" , 2x M.2, 2x LAN (Intel 1G + 2.5G), 2x COM, 24/7 Dauerbetrieb, inkl. VESA. Gehäusetyp: 1,3L Größe PC, Produkttyp: Mini-PC Barebone. Prozessorsockel: LGA 1700. Unterstützte Arbeitsspeicher: DDR4-SDRAM, Anzahl der Speichersteckplätze: 2, RAM-Speicher maximal: 64 GB. Unterstützte Speicherlaufwerke: HDD & SSD, Speicherlaufwerk Schnittstelle: M.2, SATA, Serial ATA II, Serial ATA III. Anzahl Ethernet-LAN-Anschlüsse (RJ-45): 2. Kühlung: Aktiv. Stromversorgung: 120 W
| Eingebauter Prozessor | Nein |
| Installierter interner Speicher | Nein |
| Arbeitsspeicher Typ | SO-DIMM |
| Anzahl der Speichersteckplätze | 2 |
| RAM-Speicher maximal | 64 GB |
| Unterstützte Arbeitsspeichergeschwindigkeit | 3200 MHz |
| Unterstützte Arbeitsspeicher | DDR4-SDRAM |
| Installierte Speichertreiber | Nein |
| Unterstützte Speicherlaufwerke | HDD & SSD |
| unterstützte Speicherlaufwerksgrößen | 2.5" |
| Speicherlaufwerk Schnittstelle | M.2, SATA, Serial ATA II, Serial ATA III |
| Eingebaute Grafikadapter | Ja |
| Grafikkarte-Familie | Intel |
| Maximale Auflösung | 3840 x 2160 Pixel |
| Anzahl der Display unterstützt | 3 |
| Eingebaute Lautsprecher | Nein |
| Ethernet/LAN | Ja |
| WLAN | Nein |
| Anzahl USB 2.0 Anschlüsse | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ C | 1 |
| Anzahl HDMI-Anschlüsse | 1 |
| HDMI-Version | 2.0b |
| Anzahl DisplayPort Anschlüsse | 2 |
| Mikrofon-Eingang | Ja |
| Kopfhörerausgänge | 1 |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 2 |
| Anzahl COM-Anschlüsse | 2 |
| SATA III Anschlüsse | 1 |
| Gleichstrom-Anschluss (DC) | Ja |
| Anzahl der M.2 (M)-Steckplätze | 2 |
| Gehäusetyp | 1,3L Größe PC |
| Produktfarbe | Schwarz |
| Kühlung | Aktiv |
| Ein-/Ausschalter | Ja |
| LED-Anzeigen | HDD, Leistung |
| Kabelsperre-Slot | Ja |
| Slot-Typ Kabelsperre | Kensington |
| VESA-Halterung | Ja |
| Produkttyp | Mini-PC Barebone |
| Prozessorsockel | LGA 1700 |
| Anzahl unterstützter Prozessoren | 1 |
| Unterstützt Windows-Betriebssysteme | Windows 10 x64, Windows 11 x64 |
| Unterstützte Linux-Betriebssysteme | Ja |
| Netzteiltyp | Externer AC-Adapter |
| Stromversorgung | 120 W |
| AC Eingangsspannung | 100 - 240 V |
| Netzteil Ausgangsspannung | 19 V |
| AC-Adapter Ausgangssstrom | 6,32 A |
| Breite | 165 mm |
| Tiefe | 190 mm |
| Höhe | 43 mm |
| Netzkabel enthalten | Ja |
| AC-Netzadapter | Ja |
| Schnellstartübersicht | Ja |
| Treiber enthalten | Ja |
