TRENDnet 5-Port Industrieller Gigabit PoE+ DIN-Rail-Switch
Trendnet TI-PG50. Unmanaged. Gigabit Ethernet (10/100/1000). Vollduplex. Power over Ethernet (PoE). Rack-Einbau. Wandmontage
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Trendnet TI-PG50. Switch-Typ: Unmanaged. Basic Switching RJ-45 Ethernet Ports-Typ: Gigabit Ethernet (10/100/1000). Anzahl der basisschaltenden RJ-45 Ethernet Ports: 4. Vollduplex. MAC-Adressentabelle: 2000 Eintragungen. Routing-/Switching-Kapazität: 10 Gbit/s. Netzstandard: IEEE 802.3. IEEE 802.3ab. IEEE 802.3af. IEEE 802.3at. IEEE 802.3u. IEEE 802.3x. DC input Spannung: 48 - 56 V. Power over Ethernet (PoE). Wandmontage. Rack-Einbau
| Switch-Typ | Unmanaged |
| Feature | Rackmontageset |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 4 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Netzstandard | IEEE 802.3. IEEE 802.3ab. IEEE 802.3af. IEEE 802.3at. IEEE 802.3u. IEEE 802.3x |
| Kupfer Ethernet Verkabelungstechnologie | 1000BASE-T |
| Ethernet LAN Datentransferraten | 10.100.480.800.1000 Mbit/s |
| Routing-/Switching-Kapazität | 10 Gbit/s |
| Transferrate | 7.44 Mpps |
| MAC-Adressentabelle | 2000 Eintragungen |
| Jumbo-Frames | 9000 |
| Datenpaket-Pufferspeicher | 0.128 MB |
| DHCP-Funktionen | DHCP client. DHCP server |
| Produktfarbe | Schwarz |
| Mittlere Betriebsdauer zwischen Ausfällen (MTBF) | 538451 h |
| DC input Spannung | 48 - 56 V |
| Stromverbrauch (max.) | 2.24 W |
| Power-over-Ethernet (PoE)-Typ unterstützt | Active PoE |
| Anzahl Power over Ethernet plus (PoE+) Anschlüsse | 4 |
| Power over Ethernet (PoE) Leistung pro Anschluss | 30 W |
| Gesamtleistung Power over Ethernet (PoE) | 120 W |
| Betriebstemperatur | -40 - 75 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 95% |
| Breite | 104 mm |
| Tiefe | 32 mm |
| Höhe | 82 mm |
| Gewicht | 190 g |
| Zertifizierung | CE. FCC. UL. Shock (IEC 60068-2-27). Freefall (IEC 60068-2-32). Vibration (IEC 60068-2-6). IEC 61000-4-2. IEC 61000-4-4. IEC 61000-4-5 |
| Warentarifnummer (HS) | 85176990 |
