MSI MPG X870I EDGE TI EVO WIFI (AM5)
MSI MPG X870I EDGE TI EVO WIFI, AMD, Sockel AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Sockel AM5, DDR5-SDRAM, 256 GB
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
MSI MPG X870I EDGE TI EVO WIFI. Prozessorhersteller: AMD, Prozessorsockel: Sockel AM5, Kompatible Prozessoren: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Unterstützte Arbeitsspeicher: DDR5-SDRAM, RAM-Speicher maximal: 256 GB, Arbeitsspeicher Typ: DIMM. Unterstützte Speicherlaufwerk-Schnittstellen: M.2, SATA III, Unterstützte Speicherlaufwerke: HDD & SSD, RAID Level: 0, 1, 5, 10. Ethernet Schnittstellen Typ: 5 Gigabit Ethernet, LAN-Controller: Realtek RTL8126, Top WLAN-Standard: Wi-Fi 7 (802.11be). Komponente für: PC, Motherboardformfaktor: mini ATX, Motherboard Chipsatz Familie: AMD
| Prozessorhersteller | AMD |
| Prozessorsockel | Sockel AM5 |
| Kompatible Prozessoren | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Unterstützte Prozessorsteckplätze | Sockel AM5 |
| Unterstützte Arbeitsspeicher | DDR5-SDRAM |
| Anzahl der Speichersteckplätze | 2 |
| Arbeitsspeicher Typ | DIMM |
| Speicherkanäle | Zweikanalig |
| ECC-Kompatibilität | Nicht-ECC |
| Unterstützte Arbeitsspeichergeschwindigkeit | 9000,8000,7000 MHz |
| Unterstützte Speichertaktrate (max.) | 9000 MHz |
| RAM-Speicher maximal | 256 GB |
| Unterstützte Speicherlaufwerke | HDD & SSD |
| Unterstützte Speicherlaufwerk-Schnittstellen | M.2, SATA III |
| Maximale unterstützte Anzahl der HDD | 2 |
| Anzahl der unterstützten Speicherlaufwerke | 3 |
| RAID-Unterstützung | Ja |
| RAID Level | 0, 1, 5, 10 |
| Eingebaute Grafikadapter | Nein |
| Anzahl USB 2.0 Schnittstellen | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anschlüsse | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Anschlüsse | 1 |
| SATA III Anschlüsse | 2 |
| Gesamtanzahl der SATA-Anschlüsse | 2 |
| ATX Stromstecker (24-pol.) | Ja |
| CPU Ventilatorstecker | Ja |
| EPS Stromstecker (8-pin) | Ja |
| USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Anschlüsse vom Typ A | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Anschlüsse vom Typ C | 1 |
| Anzahl USB4 Gen 2×2-Ports | 1 |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 1 |
| Anzahl HDMI-Anschlüsse | 1 |
| HDMI-Version | 2.1 |
| Anzahl DisplayPort Anschlüsse | 2 |
| Mikrofon-Eingang | Ja |
| S/PDIF-Ausgang | Ja |
| Ethernet/LAN | Ja |
| Ethernet Schnittstellen Typ | 5 Gigabit Ethernet |
| LAN-Controller | Realtek RTL8126 |
| WLAN | Ja |
| Top WLAN-Standard | Wi-Fi 7 (802.11be) |
| WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| Bluetooth | Ja |
| Bluetooth-Version | 5.4 |
| Motherboard Chipsatz | AMD X870 |
| Audio-Chip | Realtek ALC4080 |
| Audio Kanäle | 7.1 Kanäle |
| Produktfarbe | Weiß |
| PC Gesundheitsüberwachung | CPU, Ventilator, Temperatur, Spannung |
| Komponente für | PC |
| Motherboardformfaktor | mini ATX |
| Motherboard Chipsatz Familie | AMD |
| PCI-Express x16 (Gen 3.x)-Anschlüsse | 1 |
| PCI Express x16-Steckplätze (Gen 4.x) | 1 |
| PCI Express x16-Steckplätze (Gen 5.x) | 1 |
| Anzahl der M.2 (M)-Steckplätze | 1 |
| 1. M.2 größte Schlüsselgröße | 2280 |
| 1. M.2 höchste PCI Express-Generation | 5.0 |
| BIOS-Typ | UEFI AMI |
| BIOS-Speichergröße | 512 Mbit |
| ACPI-Version | 6.5 |
| Systemverwaltung BIOS (SMBIOS) Version | 3.7 |
| Breite | 170 mm |
| Tiefe | 170 mm |
