Barebone slim DN11H5 U-125H DDR5 black
Shuttle Slim AI PC DN11H5 Intel Core Ultra 5 125H, Intel Arc graphics, 2xHDMI, 2x DP, 4x 2.5Gbit LAN, VESA, 24/7 Dauerbetrieb, 1,35 l großer PC, Mini-PC Barebone, Intel SoC, DDR5-SDRAM, PCI Express, 120 W
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Shuttle Slim AI PC DN11H5 Intel Core Ultra 5 125H, Intel Arc graphics, 2xHDMI, 2x DP, 4x 2.5Gbit LAN, VESA, 24/7 Dauerbetrieb. Gehäusetyp: 1,35 l großer PC, Produkttyp: Mini-PC Barebone. Motherboard Chipsatz: Intel SoC, BIOS-Typ: UEFI AMI. Unterstützte Arbeitsspeicher: DDR5-SDRAM, Anzahl der Speichersteckplätze: 2, RAM-Speicher maximal: 96 GB. Unterstützte Speicherlaufwerke: SSD, Speicherlaufwerk Schnittstelle: PCI Express. Anzahl Ethernet-LAN-Anschlüsse (RJ-45): 4. Kühlung: Aktiv. Stromversorgung: 120 W
| Prozessorhersteller | Intel |
| Prozessorfamilie | Intel Core Ultra 5 |
| Prozessorgeneration | Intel Core Ultra (Serie 1) |
| Prozessor | 125H |
| Anzahl Prozessorkerne | 14 |
| Prozessor-Threads | 18 |
| Prozessor Boost-Frequenz | 4,5 GHz |
| Leistungskerne | 4 |
| Effiziente Kerne | 8 |
| Leistungskern maximale Turbofrequenz | 4,5 GHz |
| Effizienter Kern maximale Turbofrequenz | 3,6 GHz |
| Low Power Efficient-Core maximale Turbofrequenz | 2,5 GHz |
| Leistung Basisfrequenz des Kerns | 1,2 GHz |
| Effiziente Basisfrequenz des Kerns | 0,7 GHz |
| Low Power Efficient-Core Basisfrequenz | 700 MHz |
| Eingebauter Prozessor | Ja |
| Prozessor-Cache | 18 MB |
| Arbeitsspeicher Typ | SO-DIMM |
| Anzahl der Speichersteckplätze | 2 |
| RAM-Speicher maximal | 96 GB |
| Unterstützte Arbeitsspeichergeschwindigkeit | 5600 MHz |
| Unterstützte Arbeitsspeicher | DDR5-SDRAM |
| Speicherkanäle | Zweikanalig |
| Speicherspannung | 1.1 V |
| ECC | Nein |
| Ohne ECC | Ja |
| Unterstützte Speicherlaufwerke | SSD |
| unterstützte Speicherlaufwerksgrößen | M.2 |
| SSD-Formfaktor | M.2 |
| Speicherlaufwerk Schnittstelle | PCI Express |
| NVMe | Ja |
| Anzahl der unterstützten Speicherlaufwerke | 3 |
| Eingebaute Grafikadapter | Ja |
| Grafikkarte-Familie | Intel |
| Eingebautes Grafikkartenmodell | Intel Arc Graphics |
| Maximale Auflösung | 3840 x 2160 Pixel |
| Anzahl der Display unterstützt | 4 |
| Eingebaute Lautsprecher | Nein |
| Ethernet/LAN | Ja |
| WLAN | Nein |
| LAN-Controller | Intel I226-LM |
| USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Anschlüsse vom Typ A | 6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Anschlüsse vom Typ C | 2 |
| Anzahl HDMI-Anschlüsse | 2 |
| HDMI-Version | 2.1 |
| Anzahl DisplayPort Anschlüsse | 2 |
| DisplayPorts-Version | 1.4 |
| Mikrofon-Eingang | Ja |
| Kopfhörerausgänge | 1 |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 4 |
| Gleichstrom-Anschluss (DC) | Ja |
| Gehäusetyp | 1,35 l großer PC |
| Produktfarbe | Schwarz |
| Kühlung | Aktiv |
| Gehäusematerial | Metall |
| Kabelsperre-Slot | Ja |
| Slot-Typ Kabelsperre | Kensington |
| VESA-Halterung | Ja |
| Panel-Montage-Schnittstelle | 75 x 75,100 x 100 mm |
| Produkttyp | Mini-PC Barebone |
| Motherboard Chipsatz | Intel SoC |
| BIOS-Typ | UEFI AMI |
| Trusted Platform Module (TPM) | Ja |
| Trusted Platform Module (TPM) Version | 2.0 |
| Audio-Chip | Realtek ALC888S |
| Konformitätsbescheinigungen | BSMI, CE, Eidgenössische Kommunikationskommission (FCC), RoHS, cTUVus |
| Warentarifnummer (HS) | 84733080 |
| Unterstützt Windows-Betriebssysteme | Windows 11 x64 |
| Unterstützte Linux-Betriebssysteme | Ja |
| Nachhaltigkeitszertifikate | ENERGY STAR, ErP |
| Netzteiltyp | Externer AC-Adapter |
| Stromversorgung | 120 W |
| Anzahl von Stromversorgungseinheiten | 1 |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| Netzteil Ausgangsspannung | 19 V |
| AC-Adapter Ausgangssstrom | 6,32 A |
| Betriebstemperatur | 0 - 50 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Breite | 190 mm |
| Tiefe | 165 mm |
| Höhe | 43 mm |
| Gewicht | 1,23 kg |
| Paketgewicht | 2,46 kg |
| Netzkabel enthalten | Ja |
| AC-Netzadapter | Ja |
| Schnellstartübersicht | Ja |
