Planet SGS-6341-16S8C4XR 16-Port Managed Switch
PLANET SGS-6341-16S8C4XR. Managed. L3. Gigabit Ethernet (10/100/1000). Vollduplex. Rack-Einbau. 1U
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
PLANET SGS-6341-16S8C4XR. Switch-Typ: Managed. Switch-Ebene: L3. Basic Switching RJ-45 Ethernet Ports-Typ: Gigabit Ethernet (10/100/1000). Anzahl der basisschaltenden RJ-45 Ethernet Ports: 8. Konsolen-Port: RJ-45. Vollduplex. MAC-Adressentabelle: 16000 Eintragungen. Routing-/Switching-Kapazität: 128 Gbit/s. Netzstandard: IEEE 802.1D. IEEE 802.1Q. IEEE 802.1ab. IEEE 802.1p. IEEE 802.1s. IEEE 802.1w. IEEE 802.1x. IEEE.... DC input Spannung: 12 V. Rack-Einbau. Formfaktor: 1U
| Switch-Typ | Managed |
| Switch-Ebene | L3 |
| Feature | Stapelbar |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 8 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Menge SFP-Modul-Steckplätze | 24 |
| Menge Modul-Steckplätze SFP+ | 4 |
| Konsolen-Port | RJ-45 |
| Kupfer Ethernet Verkabelungstechnologie | 10BASE-T. 100BASE-TX. 1000BASE-LX. 1000BASE-SX. 1000BASE-T |
| Virtuelle LAN-Funktionen | IP subnet–based VLAN. MAC address-based VLAN. Private VLAN. Protocol-based VLAN. Stacked VLAN. Tagged VLAN |
| Routing-/Switching-Kapazität | 128 Gbit/s |
| Durchgang | 95.23 Mpps |
| MAC-Adressentabelle | 16000 Eintragungen |
| Anzahl der Leitungen | 128 |
| Jumbo-Frames | 10000 |
| Datenpaket-Pufferspeicher | 1.5 MB |
| IGMP-Einträge | 255 |
| Unterstützte Sicherheitsalgorithmen | MD5 |
| Authentifizierung | Port-basierte Authentifizierung |
| Autentifizierungstyp | AAA. RADIUS |
| Warteschleifenplanungs-Algorithmen | Priority queuing (PQ). Weighted Round Robin (WRR) |
| Multicast Listener Discovery (MLD) Snooping | v1/v2 |
| Router Protokoll | BGP4. BGP4+. OSPF. OSPFv3. RIP-1. RIP-2. RIPng. VRRP |
| Formfaktor | 1U |
| Produktfarbe | Schwarz |
| LED-Anzeigen | Aktivität. Link. Leistung. System |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50 - 60 Hz |
| DC input Spannung | 12 V |
| Stromverbrauch (max.) | 47.6 W |
| Betriebstemperatur | 5 - 50 °C |
| Temperaturbereich bei Lagerung | -10 - 70 °C |
| Relative Luftfeuchtigkeit in Betrieb | 5 - 90% |
| Luftfeuchtigkeit bei Lagerung | 5 - 90% |
| Breite | 440 mm |
| Tiefe | 240 mm |
| Höhe | 43.6 mm |
| Gewicht | 3.17 kg |
| Zertifizierung | FCC Part 15 Class A. CE |
| Warentarifnummer (HS) | 85176990 |
