MSI Mag A500N-H ATX power supply - 500W SI version
MSI MAG A500N-H, 500 W, 200 - 240 V, 50/60 Hz, Aktiv, 105 W, 500 W
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
MSI MAG A500N-H. Gesamtleistung: 500 W, AC Eingangsspannung: 200 - 240 V, AC Eingangsfrequenz: 50/60 Hz. Motherboard Anschlussstecker: 24-pin ATX. Zweck: PC, Stromversorgungseinheit (PSU) Formfaktor: ATX. Produktfarbe: Schwarz, Kühlung: Aktiv, Lüfterdurchmesser: 12 cm. Breite: 140 mm, Tiefe: 150 mm, Höhe: 86 mm
| Gesamtleistung | 500 W |
| AC Eingangsspannung | 200 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| Leistungsfaktorkorrekturfilter (PFC) | Aktiv |
| Kombinierter Strom (+3.3V) | 105 W |
| Kombinierter Strom (+12V) | 500 W |
| Kombinierter Strom (+5V) | 456 W |
| Kombinierter Strom (-12V) | 3,6 W |
| Kombinierter Strom (+5Vsb) | 12,5 W |
| Max. Ausgangsstrom (+3.3V) | 14 A |
| Max. Ausgangsstrom (+12V) | 38 A |
| Max Ausgangsstrom (+5V) | 14 A |
| Max. Ausgangsstrom (-12V) | 0,3 A |
| Max. Ausgangsstrom (+5Vsb) | 2,5 A |
| Motherboard Anschlussstecker | 24-pin ATX |
| Anzahl SATA Stromstecker | 3 |
| Anzahl Molex Anschlüsse 4pin | 2 |
| EPS Stromstecker (8-pin) | Nein |
| EPS-Stromanschluss (4+4-polig) | Ja |
| Anzahl PCI Express Stromstecker 6+2pin | 1 |
| ATX Stromstecker (24-pol.) | Ja |
| Zweck | PC |
| Stromversorgungseinheit (PSU) Formfaktor | ATX |
| Produktfarbe | Schwarz |
| Kühlung | Aktiv |
| Lüfterdurchmesser | 12 cm |
| Gebläsegeschwindigkeit | 500 - 1800 RPM |
| Beleuchtung | Nein |
| Breite | 140 mm |
| Tiefe | 150 mm |
| Höhe | 86 mm |
