TP-Link Archer NX200 - AX1800 5G Dual-Band Wi-Fi 6 Router - White, Gigabit Ethernet, Nano-SIM
AX1800 Wi‑Fi 6 dual-band (2.4/5 GHz) router with 5G Nano‑SIM support, 3x Gigabit LAN, internal antennas, and OpenVPN/PPTP/IPSec VPN. White tabletop design.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| Routers - Wi-Fi Standard | Wi-Fi 6 |
|---|---|
| Routers - Bands | Dual-band (2.4+5 GHz) |
| Routers - VPN | Server (OpenVPN/WireGuard/PPTP/L2TP) |
| Routers - LAN Ports | 3 |
| Routers - USB Ports | None |
| Routers - Antennas | Internal |
| Routers - 3G/4G/5G Failover | Nano-SIM (built-in) |
TP-Link Archer NX200. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz). Top Wi-Fi standard: Wi-Fi 6 (802.11ax). WLAN data transfer rate (max): 1201 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet. Ethernet LAN data rates: 10.100.1000 Mbit/s. VPN support: PPTP VPN. IPSec VPN . OpenVPN. Mobile network generation: 5G. 3G standards: DC-HSDPA. HSPA. HSPA+. UMTS. 4G standard: LTE-TDD & LTE-FDD. Security algorithms: 64-bit WEP. 128-bit WEP. WPA. WPA-PSK. WPA2. WPA2-PSK. Firewall security: IPv4 SPI Firewall. IPv6 Firewal
| Feature | Mac operating systems supported |
| WAN connection type | RJ-45 |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 1201 Mbit/s |
| Wi-Fi standards | 802.11a. 802.11b. 802.11g. Wi-Fi 4 (802.11n). Wi-Fi 5 (802.11ac). Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| WLAN data transfer rate (second band) | 1201 Mbit/s |
| Modulation | 1024-QAM |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10.100.1000 Mbit/s |
| Number of guest networks (2.4 GHz) | 1 |
| Number of guest networks (5 GHz) | 1 |
| VPN support | PPTP VPN. IPSec VPN . OpenVPN |
| Mobile network generation | 5G |
| 3G standards | DC-HSDPA. HSPA. HSPA+. UMTS |
| 4G standard | LTE-TDD & LTE-FDD |
| 5G bands supported | 700.800.850.900.1800.2100.2300.2500.2600.3500.3700 MHz |
| 4G bands supported | 700.800.850.900.1500.1800.2100.2300.2500.2600.3500.3700 MHz |
| 3G bands supported | 850.900.2100 MHz |
| SIM card type | NanoSIM |
| Ethernet LAN (RJ-45) ports | 3 |
| Security algorithms | 64-bit WEP. 128-bit WEP. WPA. WPA-PSK. WPA2. WPA2-PSK |
| Firewall security | IPv4 SPI Firewall. IPv6 Firewal |
| Supported network protocols | IPv4. IPv6 |
| Product colour | White |
| Product type | Tabletop router |
| Compliance certificates | CE. RoHS |
| Cables included | LAN (RJ-45) |
| Antenna design | Internal |
| Antennas quantity | 10 |
| Power source type | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Output voltage | 12 V |
| Output current | 2 A |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Browser supported | Internet Explorer 11. Firefox 12.0. Chrome 20.0. Safari 4.0. or other Java-enabled browser |
| Windows operating systems supported | Windows 10. Windows 2000. Windows 7. Windows 8. Windows 8.1. Windows 98SE. Windows NT. Windows Vista. Windows XP |
| Width | 99 mm |
| Depth | 99 mm |
| Height | 190 mm |
