TP-Link 5-Port Gigabit Desktop Switch - TL-SG105s - Metal Housing, Black, Unmanaged
5-Port Gigabit unmanaged desktop switch (TL-SG105s). Metal housing, plug-and-play, wall-mountable, low power (max 2.3W), 10/100/1000 Mbps ports, 1 MB buffer.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Network Switches - Fanless | Yes |
|---|
TP-Link 5-Port 10/100/1000Mbps Desktop Switch. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 2000 entries. Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.1p. IEEE 802.3. IEEE 802.3ab. IEEE 802.3u. IEEE 802.3x. Wall mountable
| Switch type | Unmanaged |
| Feature | Rubber feet |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 5 |
| Networking standards | IEEE 802.1p. IEEE 802.3. IEEE 802.3ab. IEEE 802.3u. IEEE 802.3x |
| Copper ethernet cabling technology | 10BASE-T. 100BASE-TX. 1000BASE-T |
| Cable types supported | Cat3. Cat4. Cat5. Cat5e |
| Switching capacity | 10 Gbit/s |
| Forwarding rate | 7.4 Mpps |
| MAC address table | 2000 entries |
| Jumbo frames | 16000 |
| Packet buffer memory | 1 MB |
| Product colour | Black |
| Housing material | Steel |
| Power source | DC |
| Input current | 0.6 A |
| Input voltage | 5 V |
| Output voltage | 9 V |
| Output current | 0.6 A |
| Power consumption (max) | 2.3 W |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 7.83 BTU/h |
| Width | 99.8 mm |
| Depth | 97.8 mm |
| Height | 25 mm |
| Cables included | AC |
| Package type | Box |
| Package width | 128 mm |
| Package depth | 125 mm |
| Package height | 92 mm |
| Certification | CE. FCC. RoHS |
| Harmonized System (HS) code | 85176990 |
