YS-7154CF-F2B
LANCOM YS-7154CF-F2B, Managed, L2/L3, Vollduplex, Rack-Einbau, 1U
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LANCOM YS-7154CF-F2B. Switch-Typ: Managed, Switch-Ebene: L2/L3. Konsolen-Port: RJ-45. Vollduplex. MAC-Adressentabelle: 32000 Eintragungen. Netzstandard: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x. Netzstecker: AC-Eingangsbuchse. Rack-Einbau, Formfaktor: 1U
| Switch-Typ | Managed |
| Switch-Ebene | L2/L3 |
| Quality of Service (QoS) Support | Ja |
| Web-basiertes Management | Ja |
| Traffic-Klassifizierung | Ja |
| ARP-Inspektion | Ja |
| Konfiguration der Standorteinstellungen (CLI) | Ja |
| MIB Unterstützung | MIB II, Bridge MIB, Interface MIB, SMON MIB, IGMP MIB, IEEE 802.3 MAU MIB |
| Konsolen-Port | RJ-45 |
| Anzahl QSFP28-Ports | 6 |
| Anzahl SFP28-Ports | 48 |
| Netzstecker | AC-Eingangsbuchse |
| Netzstandard | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x |
| 10G-Unterstützung | Ja |
| Port-Spiegelung | Ja |
| Vollduplex | Ja |
| IP-Routing | Ja |
| Unterstützung Datenflusssteuerung | Ja |
| Link Aggregation | Ja |
| Broadcast-Sturmkontrolle | Ja |
| Ratenbeschränkung | Ja |
| Spannbaum-Protokoll | Ja |
| VLAN-Unterstützung | Ja |
| Virtuelle LAN-Funktionen | Private VLAN |
| Anzahl der VLANs | 4093 |
| Durchsatz | 2000 Gbit/s |
| MAC-Adressentabelle | 32000 Eintragungen |
| Store-and-Forward | Ja |
| Statische Route | Ja |
| Anzahl der statischen Routen | 16000 |
| Jumbo Frames Unterstützung | Ja |
| Jumbo-Frames | 12288 |
| Datenpaket-Pufferspeicher | 32 MB |
| DHCP-Funktionen | DHCP client, DHCP relay, DHCP server |
| Zugriffkontrollliste | Ja |
| IGMP-Snooping | Ja |
| IGMP-Einträge | 2800 |
| IGMP-Proxy | Ja |
| Unterstützte Sicherheitsalgorithmen | SNMP, SNMPv2 |
| SSH-/SSL-Unterstützung | Ja |
| Passwortschutz | Ja |
| Autentifizierungstyp | RADIUS, TACACS+ |
| Multicast Unterstützung | Ja |
| Multicast Listener Discovery (MLD) Snooping | Y |
| Management-Protokolle | SNMP |
| GARP VLAN Registration Protocol (GVRP) | Ja |
| Router Protokoll | BGP4, OSPFv2, OSPFv3 |
| Rack-Einbau | Ja |
| Formfaktor | 1U |
| Produktfarbe | Schwarz |
| LED-Anzeigen | Ja |
| Anzahl Lüfter | 5 Lüfter |
| Eingebauter Prozessor | Ja |
| Prozessortaktfrequenz | 1600 MHz |
| Speichertyp | DDR4-SDRAM |
| Speicherkapazität | 8192 MB |
| Geräuschpegel | 65 dB |
| Upgradefähige Firmware | Ja |
| Energiequelle | AC |
| Netzteil enthalten | Ja |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| Stromverbrauch (max.) | 220 W |
| Betriebstemperatur | 0 - 40 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Wärmeableitung | 750 BTU/h |
| Breite | 440 mm |
| Tiefe | 440 mm |
| Höhe | 43,8 mm |
| Gewicht | 8,7 kg |
| Betriebsanleitung | Ja |
| Verpackungsbreite | 540 mm |
| Verpackungstiefe | 660 mm |
| Verpackungshöhe | 180 mm |
| Paketgewicht | 8,7 kg |
| Zolltarifnummer (TARIC) | 85176200 |
| Ursprungsland | Taiwan |
