PLANET Industrial L3+ 16-Port 1000T + 4Port 1000X SFP
PLANET IGS-6325-16T4S, Managed, L3, Gigabit Ethernet (10/100/1000), Vollduplex, Wandmontage
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
PLANET IGS-6325-16T4S. Switch-Typ: Managed, Switch-Ebene: L3. Basic Switching RJ-45 Ethernet Ports-Typ: Gigabit Ethernet (10/100/1000), Anzahl der basisschaltenden RJ-45 Ethernet Ports: 16, Konsolen-Port: RJ-45. Vollduplex. MAC-Adressentabelle: 16000 Eintragungen, Routing-/Switching-Kapazität: 40 Gbit/s. Netzstandard: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE.... DC input Spannung: 9 - 48 V. Wandmontage
| Switch-Typ | Managed |
| Switch-Ebene | L3 |
| Quality of Service (QoS) Support | Ja |
| Systemereignisprotokoll | Ja |
| MIB Unterstützung | RFC 1213, RFC 1493, RFC 1643, RFC 2863, RFC 2665, RFC 2819, RFC 2737, RFC 2618, RFC 2863, RFC 2933, RFC 3411, RFC 4292, RFC 4293, RFC 4836 |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 16 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Anzahl Faseranschlüsse | 4 |
| Optischer Kabelverbinder | SFP |
| Konsolen-Port | RJ-45 |
| Netzstandard | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G-Unterstützung | Nein |
| Port-Spiegelung | Ja |
| Vollduplex | Ja |
| Unterstützung Datenflusssteuerung | Ja |
| Link Aggregation | Ja |
| Auto MDI/MDI-X | Ja |
| Spannbaum-Protokoll | Ja |
| Auto-Negotiation-Funktion | Ja |
| VLAN-Unterstützung | Ja |
| Virtuelle LAN-Funktionen | IP subnet–based VLAN, Protocol-based VLAN, Voice VLAN |
| Anzahl der VLANs | 256 |
| Routing-/Switching-Kapazität | 40 Gbit/s |
| Durchgang | 29,76 Mpps |
| MAC-Adressentabelle | 16000 Eintragungen |
| Store-and-Forward | Ja |
| Jumbo Frames Unterstützung | Ja |
| Jumbo-Frames | 10000 |
| Datenpaket-Pufferspeicher | 32 MB |
| Zugriffkontrollliste | Ja |
| IGMP-Snooping | Ja |
| Unterstützte Sicherheitsalgorithmen | SNMP, SNMPv2, SNMPv3, SSH-2, TLS |
| Warteschleifenplanungs-Algorithmen | Weighted Round Robin (WRR) |
| Multicast Unterstützung | Ja |
| GARP VLAN Registration Protocol (GVRP) | Ja |
| Router Protokoll | OSPF |
| Produktfarbe | Blau, Grau |
| Gehäusematerial | Aluminium |
| Reset-Knopf | Ja |
| LED-Anzeigen | LAN, System |
| Internationale Schutzart (IP-Code) | IP30 |
| Wandmontage | Ja |
| DIN-Schienen-Montage | Ja |
| Speichertyp | SDRAM |
| Speicherkapazität | 512 MB |
| Flash-Speicher | 64 MB |
| Upgradefähige Firmware | Ja |
| DC input Spannung | 9 - 48 V |
| Eingangsstrom | 3.3 A |
| Power over Ethernet (PoE) | Nein |
| Betriebstemperatur | -40 - 75 °C |
| Temperaturbereich bei Lagerung | -40 - 85 °C |
| Relative Luftfeuchtigkeit in Betrieb | 5 - 95% |
| Breite | 76,8 mm |
| Tiefe | 107,3 mm |
| Höhe | 152 mm |
| Gewicht | 1,17 kg |
| Zertifizierung | FCC 15 ACE: EN55032, EN55035, EN 62368-1/IEC 62368-1: 2014IEC60068-2-32, IEC60068-2-27, IEC60068-2-6 |
| Warentarifnummer (HS) | 85176990 |
