Hanwha Techwin IP-Cam Fixed Dome 'X-Serie XNV-6080RP
Hanwha XNV-6080R, IP-Sicherheitskamera, Innen & Außen, Kabelgebunden, Digitale PTZ, Vereinfachtes Chinesisch, Traditionelles Chinesisch, Tschechisch, Deutsch, Niederländisch,..., Zimmerdecke
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Hanwha XNV-6080R. Typ: IP-Sicherheitskamera, Unterstützte Positionierung: Innen & Außen, Übertragungstechnik: Kabelgebunden. Befestigungstyp: Zimmerdecke, Produktfarbe: Elfenbein, Formfaktor: Dome. Neigungswinkelbereich: 0 - 67°, Schwenkbereich: 0 - 354°, Weißabgleich: ATW, AWC, Drinnen, Manuell, Draußen. Sensor-Typ: CMOS, Größe des Bildsensors: 25,4 / 2,8 mm (1 / 2.8"), Anzahl der effektiven Pixel (H x V): 1945 x 1097 Pixel. Brennweitenbereich: 2.8 - 12 mm
| Typ | IP-Sicherheitskamera |
| Unterstützte Positionierung | Innen & Außen |
| Übertragungstechnik | Kabelgebunden |
| PTZ Kontrolle | Ja |
| PTZ-Modi | Digitale PTZ |
| Wide Dynamic Range (WDR) | Ja |
| Tag/ Nachtmodus | Ja |
| Alarmeingabe/-ausgabe | Ja |
| Unterstützte Sprachen | Vereinfachtes Chinesisch, Traditionelles Chinesisch, Tschechisch, Deutsch, Niederländisch, Englisch, Spanisch, Französisch, Griechisch, Ungarisch, Italienisch, Japanisch, Koreanisch, Polnisch, Portugiesisch, Russisch, Schwedisch, Türkisch |
| Formfaktor | Dome |
| Befestigungstyp | Zimmerdecke |
| Produktfarbe | Elfenbein |
| Gehäusematerial | Aluminium |
| Schutzfunktion | Vandalismussicher |
| Internationale Schutzart (IP-Code) | IP67 |
| IK-Kodex | IK10 |
| Nebelsicher | Ja |
| Mindestbeleuchtung | 0 Lux |
| Neigungswinkelbereich | 0 - 67° |
| Schwenkbereich | 0 - 354° |
| Weißabgleich | ATW, AWC, Drinnen, Manuell, Draußen |
| Verschlusstyp | Elektronisch |
| Kamera Verschlusszeit | 2 - 1/12000 s |
| Anpassung der Shutter-Geschwindigkeit | Manuell |
| Größe des Bildsensors | 25,4 / 2,8 mm (1 / 2.8") |
| Vollbildverfahren | Ja |
| Sensor-Typ | CMOS |
| Anzahl der effektiven Pixel (H x V) | 1945 x 1097 Pixel |
| Brennweitenbereich | 2.8 - 12 mm |
| Maximale Blendenzahl | 3,6 |
| Nachtsicht | Ja |
| Nachtsichtdistanz | 50 m |
| LED Typ | IR |
| Maximale Auflösung | 1920 x 1080 Pixel |
| Megapixel insgesamt | 2 MP |
| Videokompressionsformate | H.264, H.265, M-JPEG, MPEG4 |
| Unterstützte Grafik-Auflösungen | 320 x 240, 640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Bis zu 30 Frames pro Sekunde | 60 fps |
| Videostreaming | Ja |
| Geräuschunterdrückung | Ja |
| 3D (Geräuschunterdrückung) | Ja |
| Verstärkungssteuerungstyp | Auto/Manuell |
| Bildqualitätsanpassung | Kontrast |
| Flip & Spiegel | Ja |
| Datenschutz-Maskierung | Ja |
| Gegenlichtkompensation | Ja |
| Highlight-Kompensation (HLC) | Ja |
| Audio-System | 2-Wege |
| Rauschverhältnis (SNR) | 50 dB |
| Sprachcodec | G.711, G.711u, G.726 |
| Ethernet/LAN | Ja |
| Ethernet Schnittstellen Typ | Schnelles Ethernet |
| Netzstandard | IEEE 802.3af |
| Unterstützte Netzwerkprotokolle | TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| WLAN | Nein |
| Bluetooth | Nein |
| Verkabelungstechnologie | 10/100Base-T(X) |
| Zahl der Benutzer | 20 Benutzer |
| Streaming-Verfahren | Multicasting, Unicast |
| Integrierter Kartenleser | Ja |
| Kompatible Speicherkarten | SD, SDHC, SDXC |
| Max. Speicherkartengröße | 512 GB |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 1 |
| Video-Bewegungsmelder | Ja |
| Aktiver Fälschungsalarm | Ja |
| IP-Adressen Filter | Ja |
| Intelligent Video Surveillance-(IVS)-System-Eigenschaften | Gesichtserkennung |
| Energiequelle | PoE |
| Stromverbrauch (max.) | 14 W |
| Stromverbrauch (Power over Ethernet (PoE)) | 12,95 W |
| Power over Ethernet (PoE) | Ja |
| Betriebstemperatur | -40 - 55 °C |
| Temperaturbereich bei Lagerung | -50 - 60 °C |
| Unterstützt Windows-Betriebssysteme | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Mac-Kompatibilität | Ja |
| Unterstützt Mac-Betriebssysteme | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra |
| Höhe | 118,5 mm |
| Durchmesser | 16 cm |
| Gewicht | 995 g |
| Anzahl der Kameras | 1 |
| USB Anschluss | Ja |
| Iris | Ja |
| Maximaler Ausgangspegel | 1 Vpp |
| Output Widerstand | 75 Ohm |
