GIGABYTE BRIX GB-BRI3H-10110 Barebone Mini PC - Black - Intel Core i3-10110U 2.1/4.1GHz - 2x SO-DIMM up to 64GB
Barebone mini PC with Intel Core i3-10110U (2.1GHz, turbo 4.1GHz), 2x DDR4 SO-DIMM up to 64GB, M.2 PCIe NVMe + 2.5" SATA, Wi-Fi 5, Bluetooth 4.2, dual HDMI, 1GbE.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Barebone & Mini PCs - Type | Barebone Kit (No RAM/SSD) |
|---|---|
| Barebone & Mini PCs - CPU Series | Intel Core i3 |
| Barebone & Mini PCs - Memory Type | DDR4 SO-DIMM |
| Barebone & Mini PCs - Memory Slots | 2 |
| Barebone & Mini PCs - Max Memory | 64 GB |
| Barebone & Mini PCs - Storage Support | M.2 NVMe |
| Barebone & Mini PCs - Graphics | Integrated |
| Barebone & Mini PCs - Video Outputs | HDMI |
| Barebone & Mini PCs - Ethernet | 1GbE |
| Barebone & Mini PCs - VESA Mount | Yes |
GIGABYTE GB-BRI3H-10110. Product type: Mini PC barebone. Processor socket: BGA 1528. Number of memory slots: 2. Maximum internal memory: 64 GB. Supported storage drive types: HDD & SSD. Storage drive interface: M.2. PCI Express. Serial ATA. Ethernet LAN (RJ-45) ports: 1. Wi-Fi standards: Wi-Fi 5 (802.11ac). Bluetooth version: 4.2. Power supply: 90 W
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i3 |
| Processor generation | 10th gen Intel® Core™ i3 |
| Processor model | i3-10110U |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor boost frequency | 4.1 GHz |
| Processor frequency | 2.1 GHz |
| Feature | Intel Virtualization Technology (VT-x) |
| Processor lithography | 14 nm |
| Thermal Design Power (TDP) | 15 W |
| Processor codename | Comet Lake |
| CPU configuration (max) | 1 |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 2666 MHz |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5" |
| SSD form factor | 2.5" |
| Storage drive interface | M.2. PCI Express. Serial ATA |
| Number of storage drives supported | 1 |
| Graphics card family | Intel |
| On-board graphics card model | Intel® UHD Graphics |
| Maximum resolution | 4096 x 2304 pixels |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| LAN controller | Realtek RTL8111HS |
| Bluetooth version | 4.2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| COM ports quantity | 1 |
| PCI Express slots version | 3.0 |
| PCI slots | 1 |
| Number of M.2 (M) slots | 1 |
| PCI Express configurations | 1x4. 2x2. 1x2+2x1. 4x1 |
| Product colour | Black |
| Cable lock slot type | Kensington |
| Panel mounting interface | 75 x 75.100 x 100 mm |
| Product type | Mini PC barebone |
| Processor socket | BGA 1528 |
| Audio chip | Realtek ALC255 |
| Intel® Turbo Boost Technology | 2.0 |
| Harmonized System (HS) code | 84713000 |
| Windows operating systems supported | Windows 10 |
| Power supply | 90 W |
| AC adapter output voltage | 19 V |
| AC adapter output current | 4.3 A |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Width | 119.5 mm |
| Depth | 119.5 mm |
| Height | 46.8 mm |
| Processor ARK ID | 196451 |
