GIGABYTE BRIX GB-BRI3H-10110 Barebone Mini PC i3-10110U 2.1/4.1GHz (Boxed)
Barebone Mini PC with Intel Core i3-10110U (2.1-4.1GHz), 2x DDR4 SO-DIMM up to 64GB@2666MHz, M.2 NVMe + 2.5in SATA, Intel WiFi 5+BT4.2, dual HDMI 4Kx2, 6x USB3.2G2, GbE, COM. VESA mount.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Barebone & Mini PC - System Type | Barebone Kit (No RAM/Storage) |
|---|---|
| Barebone & Mini PC - Processor Family | Intel Core i3 |
| Barebone & Mini PC - Graphics Chipset | Intel UHD Graphics |
| Barebone & Mini PC - Operating System | No OS |
| Barebone & Mini PC - Installed Storage | None (Barebone) |
| Barebone & Mini PC - Installed Memory (RAM) | None (Barebone) |
The GIGABYTE BRIX GB-BRI3H-10110 is a high-performance ultra-compact barebone Mini PC featuring the Intel Core i3-10110U processor (2 cores/4 threads, 2.1GHz base, 4.1GHz turbo, 15W TDP). It supports dual SO-DIMM DDR4 memory up to 64GB at 2666MHz and storage options including 1x M.2 2280 (PCIe x4/SATA) SSD and 1x 2.5" SATA HDD/SSD (7-9.5mm thick).
Connectivity is extensive with dual HDMI 2.0 ports supporting 4K@60Hz on two displays, 6x USB 3.2 Gen2 ports (including Type-C), Gigabit Ethernet (Intel i219v), Intel Dual Band Wireless-AC 3168 (Wi-Fi 5, Bluetooth 4.2), and RS232 COM port for industrial applications. Optional add-on cards provide extra LAN and COM expansion. VESA mount compatible (75x75/100x100mm).
- Ideal for: Digital signage, kiosks, home theater, office, industrial control
- Dimensions: 46.8 x 119.5 x 119.5 mm (bare unit)
- Power: 90W AC adapter (19V/4.74A)
- OS Support: Windows 10
- Graphics: Intel UHD Graphics 620
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i3 |
| Processor generation | 10th gen Intel® Core™ i3 |
| Processor model | i3-10110U |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor boost frequency | 4.1 GHz |
| Processor frequency | 2.1 GHz |
| Processor lithography | 14 nm |
| Thermal Design Power (TDP) | 15 W |
| Processor codename | Comet Lake |
| On-board graphics card model | Intel® UHD Graphics 620 |
| Maximum resolution | 4096 x 2304 pixels @60Hz |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 2666 MHz |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5 |
| SSD form factor | M.2 2280 |
| Storage drive interface | M.2 PCIe x4, Serial ATA |
| Number of storage drives supported | 2 |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| LAN controller | Intel i219v |
| Bluetooth version | 4.2 |
| USB 3.2 Gen 2 (3.1 Gen 2) ports quantity | 6 |
| HDMI ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| COM ports quantity | 1 |
| Product colour | Black |
| Panel mounting interface | 75 x 75, 100 x 100 mm |
| Product type | Mini PC barebone |
| Processor socket | BGA 1528 |
| Audio chip | Realtek ALC255 |
| Power supply | 90 W |
| AC adapter output voltage | 19 V |
| AC adapter output current | 4.74 A |
| Operating temperature (T-T) | 0 - 50 °C |
| Width | 119.5 mm |
| Depth | 119.5 mm |
| Height | 46.8 mm |
