48+4P HP Enterprise Aruba Instant On 1830 48G M RM Switch
HPE Aruba Networking Networking Instant On Switch 48p Gigabit 4p SFP 1830, Managed, L2, Gigabit Ethernet (10/100/1000), Vollduplex, Rack-Einbau, 1U
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
HPE Aruba Networking Networking Instant On Switch 48p Gigabit 4p SFP 1830. Switch-Typ: Managed, Switch-Ebene: L2. Basic Switching RJ-45 Ethernet Ports-Typ: Gigabit Ethernet (10/100/1000), Anzahl der basisschaltenden RJ-45 Ethernet Ports: 48. Vollduplex. MAC-Adressentabelle: 16000 Eintragungen, Routing-/Switching-Kapazität: 104 Gbit/s. Netzstandard: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE.... Rack-Einbau, Formfaktor: 1U
| Switch-Typ | Managed |
| Switch-Ebene | L2 |
| Quality of Service (QoS) Support | Ja |
| Web-basiertes Management | Ja |
| Cloud-verwaltet | Ja |
| Systemereignisprotokoll | Ja |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 48 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Menge SFP-Modul-Steckplätze | 4 |
| Netzstandard | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G-Unterstützung | Nein |
| Port-Spiegelung | Ja |
| Vollduplex | Ja |
| Unterstützung Datenflusssteuerung | Ja |
| Link Aggregation | Ja |
| Auto MDI/MDI-X | Ja |
| Spannbaum-Protokoll | Ja |
| Auto-Abtastung | Ja |
| VLAN-Unterstützung | Ja |
| Routing-/Switching-Kapazität | 104 Gbit/s |
| Durchgang | 77,37 Mpps |
| MAC-Adressentabelle | 16000 Eintragungen |
| Wartezeit (10-100 Mbps) | 5,2 µs |
| Wartezeit (1 Gbps) | 2,8 µs |
| Jumbo Frames Unterstützung | Ja |
| Jumbo-Frames | 9216 |
| Datenpaket-Pufferspeicher | 1,5 MB |
| DHCP-Funktionen | DHCP client |
| IGMP-Snooping | Ja |
| SSH-/SSL-Unterstützung | Ja |
| Rack-Einbau | Ja |
| Formfaktor | 1U |
| Eingebauter Prozessor | Ja |
| Prozessor | ARM Cortex-A9 |
| Prozessortaktfrequenz | 800 MHz |
| Speichertyp | SDRAM |
| Speicherkapazität | 512 MB |
| Flash-Speicher | 256 MB |
| Energiequelle | AC |
| Netzteil enthalten | Ja |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50 - 60 Hz |
| Stromverbrauch (max.) | 40,2 W |
| Leistungsaufnahme Hinweis | Maximum: 100-127V: 40.2W 200-220V: 40W; Idle: 100-127V: 17.7W 200-220V: 17.7W |
| Power over Ethernet (PoE) | Nein |
| Speicher und Prozessor | ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5 MB |
| Weitere Anschlüsse | 48 RJ-45 10/100/1000 ports, 4 SFP 1GbE ports |
| Leistungsmanagementfunktionen - Beschreibung | HPE Networking Instant On Cloud; Web browser; SNMP Manager |
| Gewicht (imperial) | 3,54 kg (7.8 Pfund) |
| Abmessungen (B x T x H) (in Zoll) | 253 x 443 x 43,9 mm (9.96 x 17.4 x 1.73") |
| Betriebstemperatur | 0 - 40 °C |
| Temperaturbereich bei Lagerung | -40 - 70 °C |
| Relative Luftfeuchtigkeit in Betrieb | 15 - 95% |
| Luftfeuchtigkeit bei Lagerung | 15 - 95% |
| Breite | 253 mm |
| Tiefe | 443 mm |
| Höhe | 43,9 mm |
| Gewicht | 3,54 kg |
| Warentarifnummer (HS) | 85176990 |
