ASROCK X299 TAICHI CLX Intel X299 S.2066
Asrock X299 Taichi CLX, Intel, LGA 2066 (Socket R4), Intel® Core™ X-Serie, DDR4-SDRAM, 256 GB, DIMM
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Asrock X299 Taichi CLX. Prozessorhersteller: Intel, Prozessorsockel: LGA 2066 (Socket R4), Kompatible Prozessoren: Intel® Core™ X-Serie. Unterstützte Arbeitsspeicher: DDR4-SDRAM, RAM-Speicher maximal: 256 GB, Arbeitsspeicher Typ: DIMM. Unterstützte Speicherlaufwerk-Schnittstellen: SATA III. Parallele Verarbeitungstechnologie: 3-Way CrossFireX, 3-Way SLI, CrossFireX, SLI. Ethernet Schnittstellen Typ: 2.5 Gigabit Ethernet, Gigabit Ethernet, LAN-Controller: Dragon RTL8125AG, Intel® I219-V, WLAN-Standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax)
| Prozessorhersteller | Intel |
| Prozessorsockel | LGA 2066 (Socket R4) |
| Kompatible Prozessoren | Intel® Core™ X-Serie |
| Maximale Anzahl an SMP-Prozessoren | 1 |
| Unterstützte Arbeitsspeicher | DDR4-SDRAM |
| Anzahl der Speichersteckplätze | 8 |
| Arbeitsspeicher Typ | DIMM |
| Speicherkanäle | Vierfach-Kanal |
| ECC-Kompatibilität | Nicht-ECC |
| Unterstützte Arbeitsspeichergeschwindigkeit | 2133,2400,2666,2800,2933,3200,3600,3733,3800,4000,4200 MHz |
| RAM-Speicher maximal | 256 GB |
| Unbuffered Speicher | Ja |
| Unterstützte Speicherlaufwerk-Schnittstellen | SATA III |
| Parallele Verarbeitungstechnologie | 3-Way CrossFireX, 3-Way SLI, CrossFireX, SLI |
| Anzahl USB 2.0 Schnittstellen | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anschlüsse | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Anschlüsse | 1 |
| SATA III Anschlüsse | 10 |
| Front Panel Audiostecker | Ja |
| ATX Stromstecker (24-pol.) | Ja |
| CPU Ventilatorstecker | Ja |
| Zahl der Chassisventilatorstecker | 5 |
| TPM-Anschluss | Ja |
| Thunderbolt-Stiftleisten | 1 |
| 12-V-Stromanschluss | Ja |
| RGB-LED-Stiftleiste | Ja |
| Anzahl USB 2.0 Anschlüsse | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Anschlüsse vom Typ C | 1 |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 2 |
| S/PDIF-Ausgang | Ja |
| Optischer Audio-Digitalausgang | 1 |
| WiFi-AP-Antennenbuchse | 2 |
| Ethernet/LAN | Ja |
| Ethernet Schnittstellen Typ | 2.5 Gigabit Ethernet, Gigabit Ethernet |
| LAN-Controller | Dragon RTL8125AG, Intel® I219-V |
| Wake-on-LAN bereit | Ja |
| WLAN | Ja |
| WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax) |
| Bluetooth | Ja |
| Bluetooth-Version | 5.0 |
| Motherboard Chipsatz | Intel® X299 |
| Audio-Chip | Realtek ALC1220 |
| Audio Kanäle | 7.1 Kanäle |
| PC Gesundheitsüberwachung | Ventilator, Temperatur, Spannung |
| Komponente für | PC |
| Motherboardformfaktor | ATX |
| Motherboard Chipsatz Familie | Intel |
| Unterstützt Windows-Betriebssysteme | Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64 |
| PCI-Express x1 (Gen 3.x)-Anschlüsse | 1 |
| PCI-Express x16 (Gen 3.x)-Anschlüsse | 4 |
| BIOS-Typ | UEFI AMI |
| BIOS-Speichergröße | 128 Mbit |
| ACPI-Version | 6.1 |
| Clear-CMOS-Taste | Ja |
| Systemverwaltung BIOS (SMBIOS) Version | 3.0 |
| Intel® Extreme Memory Profile (XMP) | Ja |
| Warentarifnummer (HS) | 84733020 |
| Breite | 305 mm |
| Tiefe | 244 mm |
| Mitgelieferte Kabel | SATA |
| Treiber enthalten | Ja |
| Schnellinstallationsanleitung | Ja |
| Nebenkosten inklusive | Ja |
| Anzahl der M.2 (E) Slots | 1 |
