Chieftec Uni XT-01B-OP - Aluminum Mini Mid Tower micro-ATX Case, 340mm GPU (Boxed)
Aluminum mini mid-tower PC case for micro-ATX boards. GPU up to 340mm, CPU cooler to 140mm. 3x 3.5in bays, 2x 5.25in ext, 2x USB-A front. Supports 80-120mm fans front/rear. Compact: 180x352x408mm, 4.5kg.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PC Cases - Motherboard Support | Micro ATX |
|---|---|
| PC Cases - Radiator Support | None |
| PC Cases - Included Fans | 0 |
| PC Cases - Front I/O | USB A |
| PC Cases - GPU Orientation | Horizontal |
| PC Cases - Form Factor | Mini Tower |
| PC Cases - Max GPU Length | 331–360 mm |
| PC Cases - Color | Black |
| PC Cases - CPU Cooler Clearance | Up to 150 mm |
The Chieftec Uni XT-01B-OP is a compact aluminum mini mid-tower case designed for micro-ATX motherboards, ideal for space-conscious builds with solid cooling support.
It accommodates GPUs up to 340mm long and CPU coolers up to 140mm high, with 4 expansion slots, 3x 3.5" internal bays (2 internal +1), 2x external 5.25" bays, and 1x 2.5" bay. Front panel features 2x USB 3.2 Gen1 Type-A ports and audio output. Fan support includes 1x 80/90/120mm front and 1x rear.
- Key Specs: Aluminum 0.6mm thick, 180mm W x 408mm D x 352mm H, 4.5kg
- Storage: Flexible 2.5"/3.5" HDD support
- Cooling: Max 120mm fans, no radiator specified
- I/O: 2x USB-A, audio
| Material | Aluminium |
| Form factor | Mini Tower |
| Type | PC |
| Supported motherboard form factors | micro ATX |
| Number of 3.5 | 3 |
| Number of 5.25 | 2 |
| Number of 2.5 | 1 |
| Number of internal 3.5 | 2 |
| Number of external 5.25 | 2 |
| Number of expansion slots | 4 |
| Maximum CPU cooler height | 14 cm |
| Maximum graphics card length | 34 cm |
| Feature | Audio output |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Number of front fans supported (max) | 1 |
| Front fans diameters supported | 80,90,120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 80,90,120 mm |
| Supported HDD sizes | 2.5,3.5 |
| Width | 180 mm |
| Depth | 408 mm |
| Height | 352 mm |
| Weight | 4.5 kg |
| Material thickness | 0.6 mm |
| Harmonized System (HS) code | 84733080 |
| Included Fans | 0 |
