ASRock B650D4U3-2L2Q - B650 Micro-ATX Motherboard - AM5, DDR5, 4x DIMM, 48GB max, Dual LAN, M.2 & SATA III
ASRock B650D4U3-2L2Q micro-ATX server motherboard for AM5 (Ryzen 7000/8000/9000, EPYC 4004). DDR5, 4 DIMM slots (48GB), M.2, 4x SATA III, dual LAN, UEFI BIOS.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Motherboards - Memory Slots | 4 |
|---|---|
| Motherboards - Main Slot PCIe Version | PCIe 4.0 |
| Motherboards - SATA Ports | 4 |
Asrock B650D4U3-2L2Q/BCM. Processor manufacturer: AMD. Processor socket: Socket AM5. Compatible processor series: AMD EPYC 4004. AMD Ryzen 7000 Series. AMD Ryzen 8000 Series. AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM. Maximum internal memory: 48 GB. Memory slots type: DIMM. Supported storage drive interfaces: M.2. SATA III. On-board graphics card model: Aspeed AST2600. Component for: Server. Motherboard form factor: micro ATX. Motherboard chipset family: AMD
| Processor manufacturer | AMD |
| Processor socket | Socket AM5 |
| Compatible processor series | AMD EPYC 4004. AMD Ryzen 7000 Series. AMD Ryzen 8000 Series. AMD Ryzen 9000 Series |
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Memory voltage | 1.1 V |
| ECC сompatibility | Non-ECC |
| Supported memory clock speeds | 3600.5600 MHz |
| Supported memory clock speed (max) | 5600 MHz |
| Maximum internal memory | 48 GB |
| Supported storage drive interfaces | M.2. SATA III |
| On-board graphics card model | Aspeed AST2600 |
| USB 2.0 connectors | 1 |
| Number of SATA III connectors | 4 |
| Feature | Clear CMOS jumper |
| Number of COM connectors | 1 |
| Serial port headers | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 2 |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| Motherboard chipset | AMD B650 Express |
| PC health monitoring | CPU. Fan. Voltage |
| Component for | Server |
| Motherboard form factor | micro ATX |
| Motherboard chipset family | AMD |
| PCI Express x4 (Gen 4.x) slots | 1 |
| BIOS type | UEFI |
| BIOS memory size | 256 Mbit |
| ACPI version | 6.4 |
| System Management BIOS (SMBIOS) version | 3.5 |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 20 - 90% |
| Width | 244 mm |
| Depth | 244 mm |
