TP-Link Omada SG2210XMP-M2 - 8x 2.5G PoE+ & 2x 10G SFP+, 160W PoE Budget, Managed L2, Black
Managed L2 switch with 8x 2.5G PoE+ RJ45 ports, 2x 10G SFP+ uplinks, 160W total PoE budget, 80 Gbps switching capacity; desktop/wall-mountable.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| Network Switches - Type | Managed L2 |
|---|---|
| Network Switches - Ports | 10 |
| Network Switches - Port Speed | Multi-Gig (2.5G) |
| Network Switches - PoE Budget | 131-250 W |
| Network Switches - Rackmount | No |
TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+. Switch type: Managed. Switch layer: L2/L2+. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500). Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 16000 entries. Switching capacity: 80 Gbit/s. Networking standards: IEEE 802.1Q. IEEE 802.1ab. IEEE 802.1p. IEEE 802.3x. Power connector: AC/DC. Power over Ethernet (PoE). Wall mountable. Rack mounting. Form factor: Desktop/Wall-Mounting
| Switch type | Managed |
| Switch layer | L2/L2+ |
| Feature | Sustainability compliance |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| SFP+ module slots quantity | 2 |
| Power connector | AC/DC |
| Networking standards | IEEE 802.1Q. IEEE 802.1ab. IEEE 802.1p. IEEE 802.3x |
| Ethernet LAN data rates | 10.100.1000.2500 Mbit/s |
| Virtual LAN features | Protocol-based VLAN. Tagged VLAN. Voice VLAN |
| Number of VLANs | 4000 |
| Switching capacity | 80 Gbit/s |
| Forwarding rate | 59.52 Mpps |
| MAC address table | 16000 entries |
| Jumbo frames | 9000 |
| Packet buffer memory | 9 MB |
| DHCP features | DHCP relay. DHCP server. DHCPv6 client. DHCPv6 snooping |
| Security algorithms | SNMP. SNMPv2. SNMPv3 |
| Authentication | MAC-based authentication. Port-based authentication |
| Authentication type | RADIUS |
| Form factor | Desktop/Wall-Mounting |
| Product colour | Black |
| Power source | AC |
| Power consumption (max) | 180.1 W |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 160 W |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 614.58 BTU/h |
| Width | 226 mm |
| Depth | 131 mm |
| Height | 35 mm |
| Compliance certificates | CE. Federal Communications Commission (FCC). RoHS |
