TP-Link VIGI NVR2016H - 16-Channel 4K Network Video Recorder, 2×SATA (up to 10TB), HDMI+VGA, Black
TP-Link VIGI NVR2016H 16-channel NVR, supports up to 3840×2160, H.265/H.264, 30fps, 2×SATA (max 10TB), HDMI+VGA output, 1×LAN, 2×USB, 12V/3.3A, black.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| NVRs - Channels | 16 |
|---|---|
| NVRs - PoE Ports | None |
| NVRs - Video Outputs | HDMI + VGA |
TP-Link VIGI NVR2016H. Video input channels: 16 channels. Maximum resolution: 3840 x 2160 pixels. Number of simultaneously playbacked channels: 16 channels. Maximum storage capacity: 10 TB. HDD interface: SATA. Ethernet LAN data rates: 10.100 Mbit/s. Supported network protocols: UPnP (Plug and Play). NTP (Network Timing). Product colour: Black. Certification: CE. EAC. UKCA. RCM. Triman. BSMI. VCCI. FCC. IC. HDMI. Power consumption (max): 24.16 W. Output current: 3.3 A. Output voltage: 12 V
| Video input channels | 16 channels |
| Number of simultaneously playbacked channels | 16 channels |
| Video recording modes | 720p. 1080p |
| Maximum resolution | 3840 x 2160 pixels |
| Feature | Reset button |
| Audio formats supported | G.711 A-law. G.711 μ-law. G.726 |
| Video formats supported | H.264. H.264+. H.265. H.265+ |
| Playback modes | Digital zoom. Fast play. Forward. Full screen. Pause. Play. Stop |
| Maximum frame rate | 30 fps |
| Input bandwidth | 80 Mbit/s |
| Output bandwidth | 60 Mbit/s |
| Recording modes | Manual. Schedule |
| HDD capacity | 0 GB |
| Number of HDDs supported | 2 |
| Maximum storage capacity | 10 TB |
| HDD interface | SATA |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10.100 Mbit/s |
| HDMI ports quantity | 1 |
| VGA (D-Sub) output ports | 1 |
| USB 2.0 ports quantity | 2 |
| eSATA ports quantity | 1 |
| Internal SATA ports quantity | 2 |
| Audio output | 1 |
| Supported network protocols | UPnP (Plug and Play). NTP (Network Timing) |
| Product colour | Black |
| Certification | CE. EAC. UKCA. RCM. Triman. BSMI. VCCI. FCC. IC. HDMI |
| Power consumption (max) | 24.16 W |
| Output current | 3.3 A |
| Output voltage | 12 V |
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Width | 330 mm |
| Depth | 285 mm |
| Height | 45 mm |
| Weight | 1.9 kg |
| Package weight | 3.2 kg |
