Samsung PM9A3 - Enterprise 2.5" NVMe SSD - 3.84TB, PCIe Gen4 x4, 6900 MB/s Read, 4100 MB/s Write
Enterprise Samsung PM9A3 2.5" NVMe PCIe Gen4 x4 SSD, 3.84TB, up to 6900 MB/s read and 4100 MB/s write, NVMe 1.4, V-NAND TLC, high IOPS for datacenter workloads.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Storage (SSD & HDD) - Type | SSD |
|---|---|
| Storage (SSD & HDD) - Interface | NVMe PCIe Gen4 x4 |
| Storage (SSD & HDD) - Form Factor | U.2 2.5inch |
| Storage (SSD & HDD) - PCIe Version (SSD) | Gen4 |
| Storage (SSD & HDD) - PCIe Lanes (SSD) | x4 |
| Storage (SSD & HDD) - NVMe Version (SSD) | 1.4 |
| Storage (SSD & HDD) - NAND Type (SSD) | 3D TLC |
| Storage (SSD & HDD) - Sequential Read (Up to) | 7000 MB/s |
| Storage (SSD & HDD) - Sequential Write (Up to) | 4500 MB/s |
| Storage (SSD & HDD) - Intended Use | Enterprise |
Samsung PM9A3. SSD capacity: 3.84 TB. SSD form factor: 2.5". Read speed: 6900 MB/s. Write speed: 4100 MB/s. Component for: PC
| NVMe version | 1.4 |
| Security algorithms | 256-bit AES |
| SSD capacity | 3.84 TB |
| SSD form factor | 2.5" |
| Interface | PCI Express 4.0 |
| Feature | End-to-End Data Protection |
| Memory type | V-NAND TLC |
| Component for | PC |
| Read speed | 6900 MB/s |
| Write speed | 4100 MB/s |
| Random read (4KB) | 1000000 IOPS |
| Random write (4KB) | 180000 IOPS |
| Sequential read speed (AS SSD) | 6900 MB/s |
| Sequential write speed (AS SSD) | 4100 MB/s |
| Controller type | Samsung Elpis |
| Mean time between failures (MTBF) | 2000000 h |
| Operating voltage | 12 V |
| Power consumption (read) | 11 W |
| Power consumption (write) | 13.5 W |
| Power consumption (max) | 3.5 W |
| Width | 110.2 mm |
| Depth | 3.8 mm |
| Height | 22 mm |
| Weight | 90 g |
| Operating temperature (T-T) | 0 - 70 °C |
| Harmonized System (HS) code | 84717070 |
