Chieftec EON ZPU-600S 600W ATX 2.3 80 PLUS Power Supply (Boxed)
Chieftec EON 600W ATX power supply with 80 PLUS efficiency, Active PFC, 2x 8-pin EPS connectors, 2x PCIe 6+2 connectors, 4x SATA, non-modular, 120mm fan, 24-month warranty.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 600 - 699 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus |
| PSU (Power Supplies) - Color | Black |
| PSU (Power Supplies) - Modularity | Non-modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 2x 8/6 pins |
| PSU (Power Supplies) - Length | Up to 140 mm |
| PSU (Power Supplies) - EPS CPU Connectors | 2x 4+4pin EPS/ATX12V |
The Chieftec EON ZPU-600S is a 600W ATX 2.3 power supply designed for budget-conscious PC builders and small servers. It features 80 PLUS Standard 230V EU efficiency certification, ensuring reliable power delivery with minimal energy waste. The unit is equipped with an Active Power Factor Correction (PFC) module and comprehensive protection systems including Over Voltage Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), Short Circuit Protection (SCP), Surge & Inrush Protection (SIP), and Automatic Fan Speed Control (AFC).
Built entirely from steel with an elegant black coating, the EON series delivers stable power across all voltage rails: +12V1 (45A), +5V (20A), +3.3V (20A), and auxiliary rails. The power supply features a quiet 120mm silent fan with automatic speed control to minimize noise during operation. All cables are extra-long native cables for flexible routing in various PC chassis. The non-modular design means all cables are permanently attached, reducing cost while maintaining full functionality for standard ATX builds.
This power supply is ideal for entry-level gaming PCs, office workstations, and small server applications requiring reliable, efficient power delivery. The compact dimensions (140 x 150 x 86mm) allow installation in most standard ATX cases.
- 600W continuous power output
- 80 PLUS Standard efficiency rating
- Active PFC (Power Factor Correction)
- 2x 8-pin EPS (4+4) CPU power connectors
- 2x PCIe 6+2 pin GPU power connectors
- 4x SATA power connectors
- 2x Molex 4-pin connectors
- 120mm silent cooling fan with AFC
- Multiple protection features (OVP, UVP, OPP, SCP, SIP)
- 24-month manufacturer warranty
- Non-modular cabling design
| Model | ZPU-600S |
| Total Power | 600 W |
| Form Factor | ATX |
| ATX Version | 2.3 |
| Efficiency Rating | 80 PLUS Standard 230V EU |
| AC Input Voltage | 200 - 240 V |
| AC Input Frequency | 50 Hz |
| Input Current | 4.5 A |
| Power Factor | >0.9 |
| Power Factor Correction | Active PFC (0.9) (only 230V) |
| +3.3V Output | 20 A |
| +5V Output | 20 A |
| +5V & +3.3V Combined | 100 W |
| +12V1 Output | 45 A |
| +12V1, +12V2 Combined | 540 W |
| -12V Output | 0.4 A / 4.8 W |
| +5VSB Output | 2.5 A / 12.5 W |
| Motherboard Connector | 1x 20+4 PIN ATX |
| CPU Power Connectors | 2x 8 PIN EPS (4+4) |
| PCIe Power Connectors | 2x 6+2 pin (8/6 pins) |
| SATA Power Connectors | 4 |
| Molex 4-pin Connectors | 2 |
| Cabling Type | Non-Modular |
| Fan Diameter | 120 mm |
| Fan Type | Silent fan with Automatic Fan Speed Control (AFC) |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
| Weight (Unit Only) | 1.34 kg |
| Weight (With Packaging) | 1.62 kg |
| Protection Features | AFC (Automatic Fan Speed Control), OPP (Over Power Protection), OVP (Over Voltage Protection), SCP (Short Circuit Protection), SIP (Surge & Inrush Protection), UVP (Under Voltage Protection) |
| Warranty | 24 Months |
| Color | Black |
| EAN Code | 0753263078438 |
