TP-Link TL-MR3020 - 3G Portable Router - 2.4 GHz Wi-Fi, 150 Mbps, USB-powered, Silver/White
TL-MR3020 portable 3G/4G router, 2.4 GHz Wi‑Fi (802.11n), USB power, 1 LAN port, compact silver/white.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| Routers - Wi-Fi Standard | Wi-Fi 4 (802.11n) |
|---|---|
| Routers - Bands | Single-band (2.4 GHz) |
| Routers - Mesh Support | None |
| Routers - USB Ports | USB 2.0 |
| Routers - Antennas | Internal |
| Routers - 3G/4G/5G Failover | USB Modem |
| Routers - App Management | No |
TP-Link TL-MR3020. WAN connection type: RJ-45. Wi-Fi band: Single-band (2.4 GHz). Top Wi-Fi standard: Wi-Fi 4 (802.11n). WLAN data transfer rate (max): 300 Mbit/s. Ethernet LAN interface type: Fast Ethernet. Ethernet LAN data rates: 10.100 Mbit/s. Networking standards: IEEE 802.11b. IEEE 802.11g. IEEE 802.11n. Mobile network generation: 4G. 3G standards: EVDO. HSPA. HSPA+. UMTS. 4G standard: LTE. Security algorithms: 64-bit WEP. 128-bit WEP. WPA-PSK. WPA2-PSK. Firewall security: DoS. SPI
| Feature | Mac operating systems supported |
| WAN connection type | RJ-45 |
| Wi-Fi band | Single-band (2.4 GHz) |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) | 300 Mbit/s |
| Wi-Fi standards | 802.11b. 802.11g. Wi-Fi 4 (802.11n) |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN data rates | 10.100 Mbit/s |
| Networking standards | IEEE 802.11b. IEEE 802.11g. IEEE 802.11n |
| Receiver sensitivity | 270M: -70dBm@10% PER130M: -73dBm@10% PER108M: -74dBm@10% PER54M: -75dBm@10% PER11M: -86dBm@8% PER6M: -92dBm@10% PER1M: -95dBm@8% PER |
| Mobile network generation | 4G |
| 3G standards | EVDO. HSPA. HSPA+. UMTS |
| 4G standard | LTE |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 1 |
| Security algorithms | 64-bit WEP. 128-bit WEP. WPA-PSK. WPA2-PSK |
| Firewall security | DoS. SPI |
| Product colour | Silver. White |
| Product type | Tabletop router |
| Compliance certificates | RoHS. Federal Communications Commission (FCC). CE |
| Cables included | LAN (RJ-45). USB |
| Antenna design | Internal |
| Transmit power | 20 dBmW |
| Power source type | USB |
| Output voltage | 5 V |
| Output current | 1 A |
| Operating temperature (T-T) | -10 - 60 °C |
| Storage temperature (T-T) | -40 - 80 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Width | 74 mm |
| Depth | 67 mm |
| Height | 22 mm |
| Package width | 110 mm |
| Package depth | 109 mm |
| Package height | 81.5 mm |
| Package weight | 210 g |
| Harmonized System (HS) code | 85176990 |
