QNAP TS-h987XU-RP-E2334-16G - 9-Bay Rack NAS, Intel Xeon E-2334, 4C/8T, 16GB DDR4 ECC
9-bay 2U rack NAS with Intel Xeon E-2334, 16 GB DDR4 ECC, HDD/SSD support, JBOD/RAID-capable, quad Ethernet.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| NAS (Network Attached Storage) - RAID Levels | JBOD |
|---|---|
| NAS (Network Attached Storage) - USB | USB 3.0 |
QNAP TS-h987XU-RP. Type: NAS. Chassis type: Rack (1U). Device class: Large Enterprise Business. Processor family: Intel Xeon E. Processor model: E-2334. Processor frequency: 3.4 GHz. Internal memory: 16 GB. Internal memory type: DDR4. Operating system installed: QuTS hero
| Storage drive interface | Serial ATA II. Serial ATA III |
| Supported storage drive interfaces | Serial ATA III. U.2 |
| Storage drive sizes supported | 2.5.3.5" |
| Feature | Fibre Channel |
| RAID levels | 0. 1. 5. 6. 10. 50. 60. JBOD |
| Supported file systems | FAT32. HFS+. NTFS. ZFS. exFAT. ext3. ext4 |
| Number of storage drives supported | 9 |
| Supported storage drive types | HDD & SSD |
| Processor manufacturer | Intel |
| Processor family | Intel Xeon E |
| Processor model | E-2334 |
| Processor frequency | 3.4 GHz |
| Processor boost frequency | 4.8 GHz |
| Processor cores | 4 |
| Processor threads | 8 |
| Processor cache | 8 MB |
| Internal memory | 16 GB |
| Internal memory type | DDR4 |
| Maximum RAM supported | 128 GB |
| Memory slots | 4 |
| Memory form factor | UDIMM |
| Flash memory | 5000 MB |
| Ethernet LAN data rates | 100.1000.2500.5000.10000 Mbit/s |
| Ethernet LAN data rate supported (max) | 10000 Mbit/s |
| Supported network protocols | IPv4. IPv6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 4 |
| Concurrent connections | 10000 |
| PCI Express x8 (Gen 4.x) slots | 1 |
| Chassis type | Rack (1U) |
| Cooling type | Active |
| Product colour | Black. Silver |
| Number of fans | 4 fan(s) |
| Fan diameter | 4 cm |
| LED indicators | HDD. LAN. Status |
| Type | NAS |
| Device class | Large Enterprise Business |
| Backup features | Cloud. iSCSI LUN |
| Management protocols | SNMP V2/V3 |
| Security algorithms | 256-bit AES. FIPS 140-2. HTTPS. SSH |
| Browser supported | Apple Safari. Google Chrome. Microsoft Edge. Mozilla Firefox |
| Share folder | Thick. Thin |
| Operating system installed | QuTS hero |
| Operating system version | h5.0.0 |
| Server operating systems supported | Windows Server 2008 R2. Windows Server 2012. Windows Server 2012 R2. Windows Server 2016. Windows Server 2019 |
| Other operating systems supported | IBM AIX 7.1. Solaris 10. Solaris 10 SPARC. Solaris 11. Solaris 11 SPARC |
| Power supply location | Built-in |
| Power supply unit (PSU) capacity | 300 W |
| Number of power supply units | 2 |
| Power consumption (typical) | 120.58 W |
| Power consumption (sleep) | 114.6 W |
| Width | 430 mm |
| Depth | 479 mm |
| Height | 43.3 mm |
| Weight | 8.43 kg |
| Package weight | 11.1 kg |
| Cables included | AC. LAN (RJ-45) |
| Power cables quantity | 2 |
| Number of screws | 52 |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 70 °C |
