Lenovo ThinkCentre M90q Gen 5 - M90q G5 - Intel i9-14900, 32GB DDR5, 1TB NVMe, Wi-Fi 6E, Black
Lenovo ThinkCentre M90q Gen5 mini PC: Intel Core i9-14900 (24C/32T, up to 5.8 GHz), 32GB DDR5, 1TB PCIe4 NVMe, Intel UHD 770, Wi-Fi 6E, Windows 11 Pro.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| Barebone & Mini PCs - Type | Mini PC (Ready-to-Use) |
|---|---|
| Barebone & Mini PCs - CPU Series | Intel Core i9 |
| Barebone & Mini PCs - Memory Type | DDR5 SO-DIMM |
| Barebone & Mini PCs - Memory Slots | 2 |
| Barebone & Mini PCs - Max Memory | 64 GB |
| Barebone & Mini PCs - Storage Support | M.2 NVMe |
| Barebone & Mini PCs - Graphics | Integrated |
| Barebone & Mini PCs - Video Outputs | DisplayPort |
| Barebone & Mini PCs - Ethernet | 1GbE |
| Barebone & Mini PCs - Wireless | Wi-Fi 6E |
| Barebone & Mini PCs - Bluetooth | 5.3 |
| Barebone & Mini PCs - OS | Windows 11 Pro |
Lenovo ThinkCentre M90q Gen 5. Processor family: Intel® Core™ i9. Processor model: i9-14900. Internal memory: 32 GB. Internal memory type: DDR5-SDRAM. Memory clock speed: 5600 MHz. Total storage capacity: 1 TB. Storage media: SSD. On-board graphics card model: Intel UHD Graphics 770. Operating system installed: Windows 11 Pro. Operating system architecture: 64-bit. Power supply: 230 W. Chassis type: Mini PC. Product type: Mini PC. Weight: 1.25 kg. Product colour: Black
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i9 |
| Processor generation | Intel® Core™ i9 (14th gen) |
| Processor model | i9-14900 |
| Processor cores | 24 |
| Processor threads | 32 |
| Processor boost frequency | 5.8 GHz |
| Performance cores | 8 |
| Efficient cores | 16 |
| Performance-core Max Turbo Frequency | 5.4 GHz |
| Efficient-core Max Turbo Frequency | 4.3 GHz |
| Performance-core base frequency | 2 GHz |
| Efficient-core base frequency | 1.5 GHz |
| Processor cache | 36 MB |
| Processor cache type | Smart Cache |
| Processor base power | 65 W |
| Maximum turbo power | 219 W |
| Internal memory | 32 GB |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 5600 MHz |
| Total storage capacity | 1 TB |
| Storage media | SSD |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | PCI Express 4.0 |
| Feature | Keyboard included |
| SSD form factor | M.2 |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card model | Intel UHD Graphics 770 |
| Ethernet LAN data rates | 100.1000 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Antenna type | 2x2 |
| Bluetooth version | 5.3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Chassis type | Mini PC |
| Colour name | Black |
| Volume | 1 L |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Motherboard chipset | Intel Q670 |
| Audio chip | Realtek ALC233 |
| Audio system | High Definition Audio |
| Number of speakers | 1 |
| Product type | Mini PC |
| Operating system architecture | 64-bit |
| Operating system language | German |
| Operating system installed | Windows 11 Pro |
| Power supply | 230 W |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50/60 Hz |
| Certification | ENERGY STAR.TCO.EPEAT Gold.RoHS |
| Width | 179 mm |
| Depth | 182.9 mm |
| Height | 36.5 mm |
| Weight | 1.25 kg |
| Mouse connectivity | Wired |
| Keyboard connectivity | Wired |
