ASRock SPC741D8UD-2T - Micro-ATX Server Motherboard, LGA4677, DDR5 8x DIMM, Dual 10GbE (Intel X550-AT2), PCIe5
Micro-ATX server motherboard for Intel Xeon LGA4677. DDR5 with 8 DIMM slots, dual 10GbE (Intel X550-AT2), PCIe Gen5 expansion, M.2, 9x SATA III, ASPEED AST2600 BMC.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| Motherboards - Form Factor | Micro-ATX |
|---|---|
| Motherboards - Memory Type | DDR5 |
| Motherboards - Memory Slots | 8 (HEDT) |
| Motherboards - PCIe Version (primary GPU) | PCIe 5.0 |
| Motherboards - M.2 Slots | 1 |
Asrock SPC741D8UD-2T/X550. Processor manufacturer: Intel. Processor socket: LGA 4677 (Socket E). Compatible processor series: Intel® Xeon®. Supported memory types: DDR5-SDRAM. Memory slots type: DIMM. Memory voltage: 1.1 V. Supported storage drive interfaces: M.2. PCI Express 3.0. SATA III. Supported storage drive types: HDD & SSD. RAID levels: 0. 1. 5. 10. Graphics card family: ASPEED. Graphics card: AST2600. Ethernet interface type: 10 Gigabit Ethernet. LAN controller: Intel® X550-AT2
| Processor manufacturer | Intel |
| Processor socket | LGA 4677 (Socket E) |
| Compatible processor series | Intel® Xeon® |
| Supported processor sockets | LGA 4677 (Socket E) |
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 8 |
| Memory slots type | DIMM |
| Memory voltage | 1.1 V |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2. PCI Express 3.0. SATA III |
| Feature | Ethernet LAN |
| RAID levels | 0. 1. 5. 10 |
| Graphics card family | ASPEED |
| Graphics card | AST2600 |
| USB 2.0 connectors | 2 |
| Number of SATA III connectors | 9 |
| Number of COM connectors | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet interface type | 10 Gigabit Ethernet |
| LAN controller | Intel® X550-AT2 |
| Motherboard chipset | Intel C741 |
| Component for | Server |
| Motherboard form factor | micro ATX |
| Motherboard chipset family | Intel |
| PCI Express x8 (Gen 5.x) slots | 2 |
| PCI Express x16 (Gen 5.x) slots | 4 |
| Number of M.2 (M) slots | 1 |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Width | 264.2 mm |
| Depth | 266.7 mm |
