GIGABIT EASY - Unmanaged L2 Gigabit Ethernet Switch, 16 Ports, 1U Rackmount (Black)
D-Link GO-SW-16G, unmanaged L2 16-port Gigabit switch, 1U rackmount, fanless, DC-powered.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Network Switches - Type | Unmanaged |
|---|---|
| Network Switches - Ports | 16 |
| Network Switches - Port Speed | Gigabit (10/100/1000) |
| Network Switches - PoE Budget | less than or equal to60 W |
| Network Switches - Rackmount | Yes |
| Network Switches - Fanless | Yes |
D-Link GO-SW-16G. Switch type: Unmanaged. Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Basic switching RJ-45 Ethernet ports quantity: 16. Full duplex. MAC address table: 8000 entries. Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.1p. IEEE 802.3. IEEE 802.3ab. IEEE 802.3az. IEEE 802.3u. IEEE 802.3x. DC input voltage: 12 V. Power connector: DC-in jack. Rack mounting. Form factor: 1U
| Switch type | Unmanaged |
| Switch layer | L2 |
| Feature | Power supply included |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 16 |
| Power connector | DC-in jack |
| Networking standards | IEEE 802.1p. IEEE 802.3. IEEE 802.3ab. IEEE 802.3az. IEEE 802.3u. IEEE 802.3x |
| Copper ethernet cabling technology | 1000BASE-T. 100BASE-TX. 10BASE-T |
| Ethernet LAN data rates | 10.100.1000 Mbit/s |
| Switching capacity | 32 Gbit/s |
| Forwarding rate | 23.81 Mpps |
| MAC address table | 8000 entries |
| Number of queues | 8 |
| Jumbo frames | 9216 |
| Packet buffer memory | 0.512 MB |
| Form factor | 1U |
| Product colour | Black |
| Housing material | Metal |
| Number of fans | 0 fan(s) |
| Mean time between failures (MTBF) | 305171 h |
| Number of power supply units | 1 |
| DC input voltage | 12 V |
| Input current | 1 A |
| Power consumption (max) | 11.7 W |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Heat dissipation | 39.92 BTU/h |
| Width | 280 mm |
| Depth | 126 mm |
| Height | 44 mm |
| Weight | 870 g |
| Package width | 180 mm |
| Package depth | 328 mm |
| Package height | 108 mm |
| Package weight | 1.45 kg |
| Shipping (inner) case height | 38.4 cm |
| Shipping (inner) case width | 34 cm |
| Shipping (inner) case length | 56.9 cm |
| Shipping (inner) case net weight | 15 kg |
| Products per shipping (inner) case | 10 pc(s) |
| Pallet gross weight (air) | 491.5 kg |
| Master (outer) cases per pallet (air) | 30 pc(s) |
| Products per pallet (air) | 300 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 2.06 m |
| Pallet gross weight (sea) | 491.5 kg |
| Master (outer) cases per pallet (sea) | 30 pc(s) |
| Products per pallet (sea) | 300 pc(s) |
| Pallet height (sea) | 2.06 m |
| Shipping (inner) case gross weight | 15.6 kg |
| Certification | CE Class A. FCC Class A. VCCI Class A. BSMI. CCCUL. CB. LVD. BSMI. CCC |
| Harmonized System (HS) code | 85176990 |
