ASUS PN64-BB5013MD - i5-12500H 4.5GHz - Black Mini PC Barebone, DDR5 SO-DIMM, Wi-Fi 6E, HDMI/DP
Barebone mini PC with Intel Core i5-12500H (up to 4.5GHz), dual DDR5 SO-DIMM slots (4800MHz), Intel Iris Xe, Wi-Fi 6E, Bluetooth 5.2, 2x HDMI, DisplayPort, 2.5GbE
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| Barebone & Mini PCs - Type | Barebone Kit (No RAM/SSD) |
|---|---|
| Barebone & Mini PCs - CPU Series | Intel Core i5 |
| Barebone & Mini PCs - Memory Type | DDR5 SO-DIMM |
| Barebone & Mini PCs - Memory Slots | 2 |
| Barebone & Mini PCs - Storage Support | 2.5inch SATA |
| Barebone & Mini PCs - Graphics | Integrated |
| Barebone & Mini PCs - Video Outputs | HDMI |
| Barebone & Mini PCs - Ethernet | 2.5GbE |
| Barebone & Mini PCs - Wireless | Wi-Fi 6E |
| Barebone & Mini PCs - Bluetooth | 5.2 |
| Barebone & Mini PCs - OS | No OS |
ASUS PN64-BB5013MD. Chassis type: Mini PC. Product type: Mini PC barebone. Supported memory types: GDDR5. Number of memory slots: 2. Supported storage drive types: HDD & SSD. Storage drive interface: Serial ATA III. Ethernet LAN (RJ-45) ports: 1. Wi-Fi standards: Wi-Fi 6E (802.11ax). Bluetooth version: 5.2
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i5 |
| Processor generation | 12th gen Intel® Core™ i5 |
| Processor model | i5-12500H |
| Processor cores | 12 |
| Processor boost frequency | 4.5 GHz |
| Feature | Intel Virtualization Technology (VT-x) |
| Processor cache | 18 MB |
| CPU configuration (max) | 1 |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Supported memory clock speeds | 4800 MHz |
| Supported memory types | GDDR5 |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5.M.2 |
| SSD form factor | M.2 |
| Storage drive interface | Serial ATA III |
| Number of storage drives supported | 2 |
| Graphics card family | Intel |
| On-board graphics card model | Intel Iris Xe Graphics |
| Discrete graphics card model | Not available |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| LAN controller | Intel WGI225V |
| Bluetooth version | 5.2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Ethernet LAN (RJ-45) ports | 1 |
| Chassis type | Mini PC |
| Product colour | Black |
| Cable lock slot type | Kensington |
| Product type | Mini PC barebone |
| Audio chip | Realtek ALC897 |
| Certification | BSMI/CB/CE/FCC/UL/CCC/Energy Star/C-Tick/WiFi/RF/VCCI |
| Width | 120 mm |
| Depth | 130 mm |
| Height | 58 mm |
| Weight | 1 kg |
