TP-Link Omada 500W AC Power Supply Module - PSM500-AC - Indoor, Metallic housing, 53.5V output
Indoor 500 W AC-DC power supply module for TP-Link Omada switches; 100–240 V input, 50/60 Hz, 53.5 V output, metallic housing.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
TP-Link PSM500-AC. Purpose: Network switch. Power supply type: Indoor. Input voltage: 100 - 240 V. Product colour: Metallic. Housing material: Metal. Width: 259.5 mm. Depth: 95.8 mm. Height: 40.1 mm. Quantity per pack: 1 pc(s)
| Purpose | Network switch |
| Power supply type | Indoor |
| Power current type | AC-to-DC |
| Input voltage | 100 - 240 V |
| Input frequency | 50/60 Hz |
| Input current | 8 A |
| Output power | 500 W |
| Output voltage | 53.5 V |
| Output current | 9.35 A |
| Power protection features | Over current. Over voltage. Short circuit. Under voltage |
| Compatibility | TP-Link SG6428XHP. SG6654XHP. S6500-24GP4XF. S6500-48GP6XF. S6500-24MPP4Y. S6500-48MPP6Y |
| Product colour | Metallic |
| Housing material | Metal |
| Feature | Suitable for indoor use |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Width | 259.5 mm |
| Depth | 95.8 mm |
| Height | 40.1 mm |
| Quantity per pack | 1 pc(s) |
