Digitus 8+4P 10G Uplink Industrial Gigabit Ethernet PoE Switch L3 managed - Black, Blue
Industrial 8x Gigabit PoE switch with 4x SFP+ uplinks; L2/L3 managed, 30W PoE budget, DC/PoE 12-48V, metal IP40, -40 to 80°C.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| Network Switches - Type | Managed L3 |
|---|---|
| Network Switches - Ports | 8 |
| Network Switches - Port Speed | Gigabit (10/100/1000) |
| Network Switches - PoE Budget | less than or equal to60 W |
Digitus Industrial 8 + 4 10G uplink port L3 managed Gigabit Ethernet PoE switch. Switch type: Managed. Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Basic switching RJ-45 Ethernet ports quantity: 8. Installed SFP+ modules quantity: 4. Full duplex. MAC address table: 32000 entries. Switching capacity: 1 Gbit/s. Networking standards: IEEE 802.3af. DC input voltage: 12 - 48 V. Power over Ethernet (PoE)
| Switch type | Managed |
| Switch layer | L2/L3 |
| Feature | Quick start guide |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Installed SFP+ modules quantity | 4 |
| Number of management ports | 1 pc(s) |
| Fiber optic connector | SFP+ |
| Networking standards | IEEE 802.3af |
| Ethernet LAN data rates | 10.100.1000 Mbit/s |
| Switching capacity | 1 Gbit/s |
| MAC address table | 32000 entries |
| Jumbo frames | 10240 |
| DHCP features | DHCP relay. DHCP server. DHCP snooping |
| Routing protocols | OSPF. OSPFv3. RIPng. VRRP |
| Product colour | Black. Blue |
| Housing material | Metal |
| International Protection (IP) code | IP40 |
| Mean time between failures (MTBF) | 300000 h |
| Power source | DC/PoE |
| DC input voltage | 12 - 48 V |
| Power consumption (typical) | 18 W |
| Surge protection voltage | 4 kV |
| Total Power over Ethernet (PoE) budget | 30 W |
| Operating temperature (T-T) | -40 - 80 °C |
| Storage temperature (T-T) | -40 - 80 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Width | 175.6 mm |
| Depth | 135 mm |
| Height | 45.5 mm |
| Weight | 800 g |
| Package width | 186 mm |
| Package depth | 72.5 mm |
| Package height | 208 mm |
| Package volume | 2804.88 cm³ |
| Package weight | 575 g |
| UK Trade Tariff code | 85176200 |
| Country of origin | China |
