Digitus 4+2P Industrial PoE Switch - L2 Managed - 4x PoE Gigabit RJ-45 + 2x SFP
Industrial L2 managed PoE switch with 4 PoE Gigabit RJ-45 ports and 2 SFP uplinks; rugged metal housing, -40 to 80°C, IP40.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| Network Switches - Type | Managed L2 |
|---|---|
| Network Switches - Port Speed | Gigabit (10/100/1000) |
| Network Switches - Rackmount | No |
Digitus Industrial 4+2 port L2 managed Gigabit Ethernet PoE switch. Switch type: Managed. Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Basic switching RJ-45 Ethernet ports quantity: 4. Installed SFP modules quantity: 2. Full duplex. MAC address table: 4000 entries. Switching capacity: 1 Gbit/s. Networking standards: IEEE 802.3af. DC input voltage: 48 - 57 V. Power over Ethernet (PoE)
| Switch type | Managed |
| Switch layer | L2 |
| Feature | Manual |
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 4 |
| Installed SFP modules quantity | 2 |
| Fiber optic connector | SFP |
| Networking standards | IEEE 802.3af |
| Ethernet LAN data rates | 10.100.1000 Mbit/s |
| Virtual LAN features | IP subnet–based VLAN. MAC address-based VLAN. Port-based VLAN. Protocol-based VLAN. Voice VLAN |
| Number of VLANs | 4094 |
| Switching capacity | 1 Gbit/s |
| Forwarding rate | 15 Mpps |
| MAC address table | 4000 entries |
| Jumbo frames | 10240 |
| Packet buffer memory | 4.1 MB |
| Product colour | Black. Blue |
| Housing material | Metal |
| International Protection (IP) code | IP40 |
| Mean time between failures (MTBF) | 300000 h |
| Power source | DC/PoE |
| DC input voltage | 48 - 57 V |
| Power consumption (typical) | 5 W |
| Surge protection voltage | 4 kV |
| Bandwidth | 20 Gbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Operating temperature (T-T) | -40 - 80 °C |
| Storage temperature (T-T) | -40 - 80 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Width | 143.7 mm |
| Depth | 104 mm |
| Height | 47.7 mm |
| Weight | 700 g |
| Package width | 158 mm |
| Package depth | 66 mm |
| Package height | 213 mm |
| Package volume | 2221.16 cm³ |
| Package weight | 735 g |
| UK Trade Tariff code | 85176200 |
| Country of origin | China |
