ARCTIC P14 PWM PST 140mm Case Fan - Black (Boxed)
140mm PWM case fan with advanced Fluid Dynamic Bearing, optimized for high static pressure cooling. Features 200-1700 RPM PWM control, PST daisy-chain technology, and 0 dB silent mode. Delivers 72.80 CFM airflow with minimal 0.3 Sone noise.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Cooling (CPU & Case) - Device Type | Case Fan |
|---|---|
| Cooling (CPU & Case) - Fan Size | 140 mm |
| Cooling (CPU & Case) - Lightning | None |
| Cooling (CPU & Case) - Connector | 4-Pin PWM |
| Cooling (CPU & Case) - Color | Black |
| Cooling (CPU & Case) - Special Features | Daisy-Chain Low Noise Magnetic Bearing |
The ARCTIC P14 PWM PST is a 140mm case fan engineered for efficient, quiet cooling in demanding PC builds. Featuring advanced Fluid Dynamic Bearing technology and a next-generation Neodymium-Iron-Boron magnet ring, this fan operates significantly more efficiently than previous generations while consuming less power and generating less heat. The innovative motor design produces only approximately 5% of the vibrations of standard DC motors, ensuring nearly imperceptible operation even at low speeds.
Optimized for high static pressure applications, the P14 PWM PST excels on heatsinks and radiators where airflow resistance is a concern. Its five large, distinctly curved blades (up to 65mm long) are engineered to maintain airflow efficiency through obstacles. The fan supports PWM control from 200 to 1700 RPM with a 0 dB silent mode below 5% PWM signal, and features PWM Sharing Technology (PST) for synchronized multi-fan operation that minimizes noise while maximizing cooling performance. With a 6-year warranty and operating temperature range of 0-40°C, this fan delivers reliable long-term performance.
Key Specifications:
- Fan Size: 140mm
- Speed Range: 200-1700 RPM (PWM controlled, 0 RPM below 5% PWM)
- Airflow: 72.80 CFM (123.76 m³/h)
- Static Pressure: 2.40 mmH₂O
- Noise Level: 0.3 Sone (22.5 dBA)
- Bearing Type: Fluid Dynamic Bearing
- Connector: 4-Pin PWM + 4-Pin Socket (PST daisy-chain capable)
- Voltage: 12V DC (Start: 3.9V)
- Power Consumption: 1.44W
- Warranty: 6 Years
| Type | Case Fan |
| Fan Size | 140mm |
| Fan Speed Range | 200-1700 RPM (PWM controlled, 0 RPM below 5% PWM) |
| Airflow | 72.80 CFM / 123.76 m³/h |
| Static Pressure | 2.40 mmH₂O |
| Noise Level | 0.3 Sone (22.5 dBA) |
| Bearing Type | Fluid Dynamic Bearing |
| Connector Type | 4-Pin PWM + 4-Pin Socket (PST) |
| Cable Length | 400mm |
| Rated Voltage | 12V DC |
| Starting Voltage | 3.9V |
| Current Draw | 0.12A @ 12V DC |
| Power Consumption | 1.44W |
| Operating Temperature | 0-40°C |
| Fan Dimensions | 140mm (L) x 140mm (W) x 27mm (H) |
| Fan Weight | 194g |
| Warranty | 6 Years |
| Special Features | PWM Sharing Technology (PST), 0 dB silent mode, Daisy-chain capable, Optimized for static pressure, Neodymium-Iron-Boron magnet, Low vibration motor design |
| Model Number | ACFAN00125A |
