DIGITUS mini GBIC (SFP) Module - 1.25 Gbps - 80km (LX, 1550 nm, LC)
Digitus mini GBIC SFP module: LX up to 80 km, 1.25 Gbps, LC, 9/125 µm fiber, 1550 nm; Tx 0-5 dBmW; Rx >= -32 dBmW; 3.3 V input.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Digitus mini GBIC (SFP) Module. 1.25 Gbps. 80km. SFP transceiver type: Fiber optic. Maximum data transfer rate: 1250 Mbit/s. Interface type: SFP. Brand compatibility: MSA Compliant. Input voltage: 3.3 V. Package width: 115 mm. Package depth: 90 mm. Package volume: 310.5 cm³. Country of origin: China
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 1250 Mbit/s |
| Interface type | SFP |
| Feature | Hot-Plug support |
| Fiber optic connector | LC |
| Fiber cable diameters supported (core/cladding) | 9/125 µm |
| SFP transceiver standard | LX |
| Maximum transfer distance | 80000 m |
| Wavelength | 1550 nm |
| Tx power (min) | 0 dBmW |
| Tx power (max) | 5 dBmW |
| Rx power (min) | -32 dBmW |
| Ethernet interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.3z |
| Cabling technology | 1000Base-LX |
| Fiber ports quantity | 1 |
| Brand compatibility | MSA Compliant |
| Input voltage | 3.3 V |
| Package width | 115 mm |
| Package depth | 90 mm |
| Package volume | 310.5 cm³ |
| Package weight | 35.417 g |
| UK Trade Tariff code | 85176200 |
| Harmonized System (HS) code | 85369010 |
| Country of origin | China |
