Barebone ASUS TS100-E11-PI4 300W
ASUS TS100-E11-PI4. Intel C256. LGA 1200 (Socket H5). Intel. Intel® Xeon®. DDR4-SDRAM. 8GB. 16GB. 32GB
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| Barebone & Mini PCs - Type | Barebone Kit (No RAM/SSD) |
|---|---|
| Barebone & Mini PCs - Max Memory | 128 GB |
| Barebone & Mini PCs - Storage Support | M.2 NVMe |
| Barebone & Mini PCs - Video Outputs | HDMI |
ASUS TS100-E11-PI4. Motherboard chipset: Intel C256. Processor socket: LGA 1200 (Socket H5). Processor manufacturer: Intel. Supported memory types: DDR4-SDRAM. Supported DIMM module capacities: 8GB. 16GB. 32GB. Maximum internal memory: 128 GB. Storage drive sizes supported: 2.5.3.5.M.2. Supported storage drive types: HDD & SSD. SSD form factor: M.2. Ethernet interface type: Fast Ethernet. Gigabit Ethernet. Ethernet LAN data rates: 10.100.1000 Mbit/s. Chassis type: Tower. Product colour: Black. Certification: BSMI. CE. FCC(Class B)
| Motherboard chipset | Intel C256 |
| Processor socket | LGA 1200 (Socket H5) |
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® |
| Number of processors supported | 1 |
| Number of DIMM slots | 4 |
| Supported memory types | DDR4-SDRAM |
| Supported DIMM module capacities | 8GB. 16GB. 32GB |
| Maximum internal memory | 128 GB |
| Buffered memory type | Unregistered (unbuffered) |
| Supported UDIMM clock speeds | 3200 MHz |
| Memory channels | Dual-channel |
| Feature | Reset button |
| Number of 2.5" bays | 1 |
| Number of 3.5" bays | 3 |
| Storage drive sizes supported | 2.5.3.5.M.2 |
| Supported storage drive types | HDD & SSD |
| SSD form factor | M.2 |
| Ethernet interface type | Fast Ethernet. Gigabit Ethernet |
| Ethernet LAN data rates | 10.100.1000 Mbit/s |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| PS/2 ports quantity | 1 |
| Headphone outputs | 1 |
| Number of SATA III connectors | 8 |
| PCI Express slots version | 4.0 |
| Number of M.2 (M) slots | 2 |
| Chassis type | Tower |
| Product colour | Black |
| Certification | BSMI. CE. FCC(Class B) |
| Power supply | 300 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Width | 190 mm |
| Depth | 423 mm |
| Height | 435 mm |
| Weight | 11.6 kg |
| Package weight | 14.7 kg |
