ICY BOX IB-PCI207-1NVMe PCIe x4 to M.2 NVMe 2280/2260/2242 w/ Heatsink (Boxed)
PCIe x4 to single M.2 NVMe adapter card from ICY BOX supports 2280/2260/2242 SSDs with integrated heatsink for optimal thermal performance. Includes full and low-profile brackets. Ideal for expanding NVMe storage in desktops.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Expansion Cards - Product Type | Storage Controller and Adapter |
|---|---|
| Expansion Cards - Host Interface | PCIe x4 |
| Expansion Cards - Internal Connectivity | M.2 NVMe and SATA |
| Expansion Cards - Form Factor | Low Profile Half-Height Standard Profile Full-Height |
| Expansion Cards - External Connectivity | Internal Only |
The ICY BOX IB-PCI207-1NVMe is a high-performance PCI Express 3.0 x4 adapter card that adds a single M.2 NVMe SSD slot to your desktop PC. Compatible with popular M.2 sizes including 2280, 2260, and 2242, it features an integrated aluminum heatsink to maintain optimal SSD temperatures during intensive workloads.
This adapter supports PCIe NVMe (M-key) SSDs and is backward compatible with PCIe 2.0 systems. It comes with both full-height and low-profile brackets, making it suitable for standard ATX cases as well as compact SFF builds. No additional drivers are required for modern operating systems including Windows 10/11, Linux, and macOS.
- PCIe 3.0 x4 interface for maximum NVMe bandwidth
- Supports M.2 NVMe SSDs (2280/2260/2242)
- Integrated heatsink with thermal pads
- Full and low-profile mounting brackets included
- Plug-and-play installation
- OS independent compatibility
| Model | IB-PCI207-1NVMe |
| Type | PCI Express to M.2 NVMe Adapter |
| Host Interface | PCIe 3.0 x4 |
| Supported SSD Interface | M.2 NVMe (PCIe) |
| Supported SSD Sizes | 2280 / 2260 / 2242 |
| Heatsink | Yes, Aluminum |
| Profile Brackets | Full-height + Low-profile |
| SSD Key | M-key |
| Dimensions (Card) | 182 x 120 x 16 mm |
| Weight (Card) | 85 g |
