Kingston ValueRAM KVR32N22S8/8 DDR4 3200MHz CL22 8GB 288-pin DIMM (Boxed)
Kingston ValueRAM KVR32N22S8/8 8GB DDR4-3200 CL22 unbuffered NON-ECC 288-pin DIMM. JEDEC standard, 1.2V, timings 22-22-22. Ideal for desktops, reliable upgrade for multitasking and gaming.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| RAM Memory - Memory Type | DDR4 |
|---|---|
| RAM Memory - Profiles | None |
| RAM Memory - ECC | Non ECC |
| RAM Memory - CAS Latency | CL22 |
| RAM Memory - RGB Lighting | No |
| RAM Memory - Total Capacity | 8 GB |
| RAM Memory - Color | Green (PCB) |
| RAM Memory - Speed (MT/s) | 3200 MT/s |
| RAM Memory - Kit Size | 1 |
| RAM Memory - Heatsink | No |
Kingston ValueRAM KVR32N22S8/8 is a high-performance 8GB DDR4 memory module designed for desktop PCs and servers. Operating at 3200MT/s (PC4-25600) with CAS Latency of 22 and timings 22-22-22, it delivers smooth multitasking, faster load times, and enhanced productivity for gaming, content creation, and everyday computing. This unbuffered, non-ECC 288-pin DIMM uses standard JEDEC timings at 1.2V, ensuring broad compatibility with motherboards supporting DDR4-3200 UDIMM.
Built with quality components, gold contact fingers, and rigorous testing, it offers legendary Kingston reliability and lifetime warranty. Single-rank (1Rx8) configuration with 1024M x 64 module setup provides stable performance without overclocking profiles like XMP. RoHS compliant, halogen-free, and operates from 0-85°C. No heatsink or RGB lighting for cost-effective, low-profile design with green PCB.
- ✅ 8GB capacity, 3200MHz speed
- ✅ CL22, unbuffered NON-ECC
- ✅ 1.2V, 288-pin DIMM for desktops
- ✅ JEDEC standard, no XMP
- ✅ Lifetime Kingston warranty
| Buffered memory type | Unregistered (unbuffered) |
| CAS latency | 22 |
| Internal memory | 8 GB |
| Memory layout (modules x size) | 1 x 8 GB |
| Internal memory type | DDR4 |
| Component for | PC/Server |
| Memory form factor | 288-pin DIMM |
| Memory ranking | 1 |
| Memory voltage | 1.2 V |
| Module configuration | 1024M x 64 |
| Row cycle time | 45.75 ns |
| Refresh row cycle time | 350 ns |
| Row active time | 32 ns |
| Programming power voltage (VPP) | 2.5 V |
| Country of origin | Taiwan |
| Lead plating | Gold |
| Feature | JEDEC standard |
| Operating temperature (T-T) | 0 - 85 °C |
| Storage temperature (T-T) | -55 - 100 °C |
| Compliance certificates | RoHS |
| Doesn't contain | Halogen |
| Width | 133.3 mm |
| Height | 31.2 mm |
| Harmonized System (HS) code | 84733020 |
| Timings | 22-22-22 |
| ECC | Non-ECC |
| Rank | 1Rx8 |
| Heatsink | No |
| Profiles | None |
