Kingston ValueRAM KVR32N22S6/8 8GB DDR4-3200 CL22 UDIMM (Retail)
Kingston ValueRAM 8GB DDR4-3200 CL22 single-rank unbuffered DIMM with 1.2V operation, non-ECC, standard height module for desktop and workstation systems.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| RAM Memory - Memory Type | DDR4 |
|---|---|
| RAM Memory - Profiles | None |
| RAM Memory - ECC | Non ECC |
| RAM Memory - CAS Latency | CL22 |
| RAM Memory - RGB Lighting | No |
| RAM Memory - Total Capacity | 8 GB |
| RAM Memory - Speed (MT/s) | 3200 MT/s |
| RAM Memory - Kit Size | 1 |
| RAM Memory - Heatsink | No |
The Kingston ValueRAM KVR32N22S6/8 is an 8GB DDR4-3200 memory module designed for mainstream desktop and workstation applications. This single-rank UDIMM operates at 1.2V with CAS latency of 22 cycles, providing reliable performance for everyday computing tasks. The module features 288-pin connectivity and is based on four 1G x 16-bit FBGA components, delivering a 1G x 64-bit configuration.
Built to JEDEC DDR4-3200 standards, this non-ECC unbuffered module includes on-die VREFDQ generation and calibration, data bus inversion (DBI) for improved signal integrity, and an on-board I2C serial presence-detect (SPD) EEPROM. The module operates within a temperature range of 0°C to 85°C and is RoHS compliant and halogen-free, making it suitable for environmentally conscious deployments. The standard height design (31.25mm) ensures compatibility with most desktop and workstation systems without clearance issues.
Kingston ValueRAM memory is backed by comprehensive compatibility testing and is ideal for users seeking reliable, cost-effective memory upgrades for their systems.
- Capacity: 8GB (1G x 64-bit)
- Speed: DDR4-3200 (PC4-25600)
- CAS Latency: CL22
- Voltage: 1.2V
- ECC: Non-ECC
- Rank: Single Rank (1Rx16)
- Form Factor: 288-pin UDIMM
- Height: 31.25mm (Standard)
- Temperature Range: 0°C to 85°C
- Compliance: RoHS Compliant, Halogen-Free
| Capacity | 8GB |
| Memory Type | DDR4 SDRAM |
| Speed | 3200 MT/s (PC4-25600) |
| CAS Latency | CL22 |
| Voltage | 1.2V |
| ECC | Non-ECC |
| Buffered/Registered | Unbuffered |
| Rank | Single Rank (1Rx16) |
| Form Factor | 288-pin UDIMM |
| Module Height | 31.25mm (Standard) |
| Chip Organization | 1G x 16-bit |
| Data Width | 64-bit |
| Memory Depth | 1G |
| Operating Temperature | 0°C to 85°C |
| Storage Temperature | -40°C to 85°C |
| Row Cycle Time (tRC) | 45.75ns (minimum) |
| Heat Spreader | No |
| RGB Lighting | No |
| Features | Data Bus Inversion (DBI), On-die VREFDQ generation and calibration, On-board I2C SPD EEPROM, 8 internal banks, Fly-by topology, Terminated control/command/address bus |
| Compliance | RoHS Compliant, Halogen-Free |
| Manufacturer Part Number | KVR32N22S6/8 |
| EAN13 | 0740617310870 |
| Packaging | Retail |
