Power Supply Asus TUF Gaming 850W Gold 80+ ATX Fully Modular - 90YE00S2-B0NA00 (Boxed)
850W ATX PSU, 80+ Gold certified, fully modular with 1x PCIe 16-pin (600W), 3x 8-pin, 2x CPU 4+4-pin. Military-grade components, 92% efficiency, 10-year warranty, 135mm fan with 0dB mode.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 800 - 899 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus Gold |
| PSU (Power Supplies) - Color | Black |
| PSU (Power Supplies) - Modularity | Fully modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 1x 12VHPWR 16-pin 3x 8/6 pins |
| PSU (Power Supplies) - Length | 141-160 mm |
| PSU (Power Supplies) - EPS CPU Connectors | 2x 4+4pin EPS/ATX12V |
The ASUS TUF Gaming 850W Gold (90YE00S2-B0NA00) is a resilient ATX power supply engineered for long-term reliability, featuring military-grade 105°C capacitors rated for 170,000 hours and full PCB protection.
80 PLUS Gold certified with up to 92% efficiency using low-ESR Japanese capacitors, it supports ATX 3.0 and PCIe 5.0 with a native 16-pin (12VHPWR) connector for up to 600W GPU power, plus 3x 8-pin PCIe, 2x 4+4-pin CPU, 5x SATA, and 4x Peripheral connectors. All cables are fully modular with premium etched sleeving for easy management.
- Fan: 135mm Axial-tech with dual-ball bearing and 0dB technology (fan stops at low loads)
- Protections: OPP/OVP/UVP/SCP/OCP/OTP
- Warranty: 10 years worldwide
- Dimensions: 150 x 150 x 86 mm; Weight: 2.38 kg
- MTBF: >120,000 hours at 40°C
| Total power | 850 W |
| AC input voltage | 100 - 240 V |
| AC input range | 100-240Vac |
| Combined power (+3.3V) | 130 W |
| Combined power (+5V) | 130 W |
| Combined power (+12V) | 850 W |
| Combined power (-12V) | 9.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 25 A |
| Max output current (+5V) | 25 A |
| Max output current (+12V) | 70.8 A |
| Max output current (-12V) | 0.8 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 92% |
| 80 PLUS certification | 80 PLUS Gold |
| Power protection features | OPP/OVP/UVP/SCP/OCP/OTP |
| ATX version | 3.0 |
| MTBF | >120,000 hrs @ 40°C |
| Motherboard power connector | 24/20-pin x 1 |
| CPU power connector | 4+4-pin x 2 |
| PCI Express power connectors (16-pin) | 1 |
| PCI Express power connectors (8-pin) | 3 |
| Number of SATA power connectors | 5 |
| Peripheral (Molex) power connectors | 4 |
| Cabling type | Fully-Modular |
| Fan diameter | 13.5 cm |
| 0dB Technology | Supported |
| Product colour | Black |
| Width | 150 mm |
| Depth | 150 mm |
| Height | 86 mm |
| Weight | 2.38 kg |
