Power Supply - PRO-WS-3000P - Black, Box, 3000W, ATX 3.1, 80+ Platinum, Fully Modular
Power supply PRO-WS-3000P: 3000W, 80+ Platinum, fully modular, ATX 3.1, black, active cooling, box packaging; multiple PCIe and SATA connectors
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Modularity | Fully modular |
|---|---|
| PSU (Power Supplies) - Length | 141-160 mm |
ASUS Pro WS 3000W Platinum
The ASUS Pro WS 3000W Platinum PSU is engineered to support up to four GeForce RTX™ 5090 graphics cards. It also features 80 PLUS Platinum certification, high-performance copper pins, dual-ball fan bearings, etched cables, rock-solid voltage stability and advanced power delivery, making it an ideal choice for AI solutions, deep learning and IT management.
| Total power | 3000 W |
| AC input voltage | 220 - 240 V |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 130 W |
| Combined power (+12V) | 3000 W |
| Combined power (+5V) | 130 W |
| Combined power (-12V) | 0.8 W |
| Combined power (+5Vsb) | 3 W |
| Max output current (+3.3V) | 25 A |
| Max output current (+12V) | 250 A |
| Max output current (+5V) | 25 A |
| Max output current (-12V) | 9.6 A |
| Max output current (+5Vsb) | 15 A |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 61 cm |
| Number of SATA power connectors | 12 |
| SATA power cable length | 120, 400 mm |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| Peripheral (Molex) power cable length | 150, 400 mm |
| PCI Express power connectors (6+2 pin) | 4 |
| PCI Express power connectors (16-pin) | 4 |
| PCI Express power cable length | 75 cm |
| CPU power connector (4+4 pin) | Yes |
| CPU power cable length | 100 cm |
| Cabling type | Fully-Modular |
| 80 PLUS certification | 80 PLUS Platinum |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| Bearing technology | DBB |
| Product colour | Black |
| Cooling type | Active |
| Width | 175 mm |
| Depth | 150 mm |
| Height | 86 mm |
| Weight | 2.16 kg |
| Package width | 346 mm |
| Package depth | 208 mm |
| Package height | 144 mm |
| Package weight | 5.09 kg |
| Package type | Box |
