ARUBA ION - 1960 - 8G 4P2.5 2-STOCK
HPE Aruba Instant On switch: 8x Gigabit RJ45, 4x 2.5G, 2x 10G copper, 2x SFP+, PoE budget 480W, 1U rack- and wall-mountable, managed, L2+.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| Network Switches - Type | Managed L2 |
|---|---|
| Network Switches - Ports | 8 |
| Network Switches - Port Speed | Gigabit (10/100/1000) |
| Network Switches - PoE Budget | greater than250 W |
| Network Switches - Rackmount | Yes |
HPE Networking Instant On Switch 8p Gigabit CL4 4p SR2.5G CL6 PoE 2p 10GBT 2p SFP+ 480W 1960. Switch type: Managed. Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 16000 entries. Switching capacity: 116 Gbit/s. Networking standards: IEEE 802.1D. IEEE 802.1Q. IEEE 802.1ab. IEEE 802.1p. IEEE 802.1s. IEEE 802.1w. IEEE 802.3. IEEE.... Power over Ethernet (PoE). Wall mountable. Rack mounting. Form factor: 1U
| Switch type | Managed |
| Switch layer | L2+ |
| Feature | Power over Ethernet (PoE) |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| 2.5G Ethernet (copper) ports quantity | 4 |
| 10G Ethernet (copper) ports quantity | 2 |
| SFP+ module slots quantity | 2 |
| Switching capacity | 116 Gbit/s |
| Throughput | 172 Mpps |
| MAC address table | 16000 entries |
| Latency (10-100 Mbps) | 4.1 µs |
| Latency (1 Gbps) | 1.8 µs |
| Latency (10 Gbps) | 2.8 µs |
| Jumbo frames | 9216 |
| Packet buffer memory | 1.5 MB |
| DHCP features | DHCP relay. DHCP snooping |
| Authentication | Port-based authentication |
| Authentication type | RADIUS |
| Management protocols | SNMPv1. SNMPv2c. SNMPv3 |
| Supported network protocols | HTTPS |
| Form factor | 1U |
| Physical stacking (units) | 4 |
| Processor model | ARM Cortex-A9 |
| Processor frequency | 800 MHz |
| Memory type | DDR3-SDRAM |
| Internal memory | 1024 MB |
| Flash memory | 512 MB |
| Power source | AC |
| AC input voltage | 200 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 623 W |
| Total Power over Ethernet (PoE) budget | 480 W |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 15 - 95% |
| Storage relative humidity (H-H) | 15 - 90% |
| Operating altitude | 0 - 3000 m |
| Width | 402.8 mm |
| Depth | 442.5 mm |
| Height | 44 mm |
| Weight | 5.24 kg |
