Cudy - GS108 - 8P
8P Cudy GS108 – 8-port Gigabit Ethernet switch (10/100/1000) with full duplex.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| Network Switches - Ports | 8 |
|---|---|
| Network Switches - Port Speed | Gigabit (10/100/1000) |
Cudy GS108. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 1000 entries. Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.3. IEEE 802.3ab. IEEE 802.3u. IEEE 802.3x. DC input voltage: 5 V
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking standards | IEEE 802.3. IEEE 802.3ab. IEEE 802.3u. IEEE 802.3x |
| Copper ethernet cabling technology | 10BASE-T. 100BASE-TX. 1000BASE-TX |
| Cable types supported | Cat3. Cat4. Cat5. Cat5e. Cat6. Cat6+. Cat6a. Cat6e. Cat7. Cat7e. Cat8. Cat8.1 |
| Feature | Quick start guide |
| Ethernet LAN data rates | 10.100.1000 Mbit/s |
| Switching capacity | 16 Gbit/s |
| Throughput | 11.9 Mpps |
| MAC address table | 1000 entries |
| Jumbo frames | 2000 |
| Packet buffer memory | 2.5 MB |
| Product colour | Black |
| LED indicators | Loop. Link. Power |
| Mean time between failures (MTBF) | 100000 h |
| Power source | AC/DC |
| AC input voltage | 100 - 240 V |
| DC input voltage | 5 V |
| Operating temperature (T-T) | -10 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating altitude | 0 - 3048 m |
| Width | 137 mm |
| Depth | 77 mm |
| Height | 25 mm |
| Weight | 300 g |
| Cables included | DC |
| Package type | Box |
| Package width | 175 mm |
| Package depth | 120 mm |
| Package height | 63 mm |
| Package weight | 500 g |
| Master (outer) case width | 505 mm |
| Master (outer) case length | 320 mm |
| Master (outer) case height | 400 mm |
| Master (outer) case gross weight | 21 kg |
| Products per master (outer) case | 40 pc(s) |
