Cisco Catalyst 1300 - 12-Port 10GE
Managed Cisco Catalyst 1300 switch with 12 ports at 10G. L2/L3 capabilities, rack-mountable.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Cisco Catalyst 1300-24FP-4X Managed Switch. 24 Port GE. Full PoE. 4x10GE SFP+. Limited Lifetime Protection (C1300-24FP-4X). Switch type: Managed. Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000). Basic switching RJ-45 Ethernet ports quantity: 12. Console port: RJ-45/USB Type-C. MAC address table: 16000 entries. Switching capacity: 480 Gbit/s. Networking standards: IEEE 802.1D. IEEE 802.1Q. IEEE 802.1ab. IEEE 802.1s. IEEE 802.1w. IEEE 802.1x. IEEE 802.3. IEEE.... Rack mounting
| Switch type | Managed |
| Switch layer | L2/L3 |
| Feature | Plug and Play |
| Basic switching RJ-45 Ethernet ports quantity | 12 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| SFP+ module slots quantity | 12 |
| Console port | RJ-45/USB Type-C |
| Cable types supported | Cat5e |
| QinQ implementation | Selective QinQ |
| Virtual LAN features | Private VLAN. Voice VLAN |
| Switching capacity | 480 Gbit/s |
| MAC address table | 16000 entries |
| Number of queues | 8 |
| Number of static routes | 990 |
| Jumbo frames | 9000 |
| Packet buffer memory | 8 MB |
| DHCP features | DHCP auto-config. DHCP client. DHCP relay. DHCP server. DHCP snooping |
| Access Control List (ACL) rules | 1024 |
| Security algorithms | HTTPS. SNMP. SNMPv2. SNMPv3. SSH. SSH-2 |
| Authentication | MAC-based authentication. Web-based authentication |
| Authentication type | RADIUS. TACACS+ |
| Queue scheduling algorithms | Weighted Round Robin (WRR) |
| IPv4 & IPv6 features | ICMPv6. IPv6 SNMP. IPv6 SSH. IPv6 TFTP. IPv6 Telnet |
| Product colour | Grey |
| Processor frequency | 1.4 MHz |
| Memory type | DDR4-SDRAM |
| Internal memory | 1000 MB |
| Flash memory | 512 MB |
| Noise level | 39 dB |
| Mean time between failures (MTBF) | 427188 h |
| Power source | AC |
| AC input voltage | 100 - 220 V |
| AC input frequency | 50/60 Hz |
| Power consumption (typical) | 88.2 W |
| Power plug type | Type C |
| Operating temperature (T-T) | -5 - 50 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 300.76 BTU/h |
| Width | 445 mm |
| Depth | 350 mm |
| Height | 44 mm |
| Weight | 4.2 kg |
| Package width | 430 mm |
| Package depth | 574.7 mm |
| Package height | 105.9 mm |
| Package weight | 5.6 kg |
| Certification | UL (UL 62368). CSA (CSA 22.2). CE mark. FCC Part 15 (CFR 47) Class A |
| Country of origin | China |
