Cisco Catalyst 1300 - 8-Port 2.5GE
Managed Cisco Catalyst C1300-24MGP-4X switch with 8x 2.5GE ports, PoE, L2/L3 capabilities, and rack-mount support.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Cisco Catalyst C1300-24MGP-4X. Switch type: Managed. Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 16000 entries. Switching capacity: 152 Gbit/s. Networking standards: IEEE 802.1D. IEEE 802.1Q. IEEE 802.1ab. IEEE 802.1s. IEEE 802.1w. IEEE 802.1x. IEEE 802.3. IEEE.... Power over Ethernet (PoE). Rack mounting
| Switch type | Managed |
| Switch layer | L2/L3 |
| Feature | Power over Ethernet (PoE) |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| 2.5G Ethernet (copper) ports quantity | 8 |
| SFP+ module slots quantity | 4 |
| QinQ implementation | Selective QinQ |
| Virtual LAN features | Private VLAN. Voice VLAN |
| Switching capacity | 152 Gbit/s |
| MAC address table | 16000 entries |
| Number of queues | 8 |
| Number of static routes | 990 |
| Jumbo frames | 9000 |
| Packet buffer memory | 1.5 MB |
| DHCP features | DHCP auto-config. DHCP client. DHCP relay. DHCP server. DHCP snooping |
| Access Control List (ACL) rules | 1024 |
| Security algorithms | HTTPS. SNMP. SNMPv2. SNMPv3. SSH. SSH-2 |
| Authentication | MAC-based authentication. Web-based authentication |
| Authentication type | RADIUS. TACACS+ |
| Queue scheduling algorithms | Weighted Round Robin (WRR) |
| IPv4 & IPv6 features | ICMPv6. IPv6 SNMP. IPv6 SSH. IPv6 TFTP. IPv6 Telnet |
| Product colour | Grey |
| Processor frequency | 1.4 MHz |
| Memory type | DDR4-SDRAM |
| Internal memory | 1000 MB |
| Flash memory | 512 MB |
| Power source | AC |
| AC input voltage | 100 - 220 V |
| AC input frequency | 50/60 Hz |
| Power plug type | Type C |
| Operating temperature (T-T) | -5 - 50 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Width | 445 mm |
| Depth | 350 mm |
| Height | 44 mm |
| Weight | 5.53 kg |
| Package width | 511.6 mm |
| Package depth | 574.7 mm |
| Package height | 108 mm |
| Package weight | 7.27 kg |
| Certification | UL (UL 62368). CSA (CSA 22.2). CE mark. FCC Part 15 (CFR 47) Class A |
| Country of origin | China |
