FSP ADVAN GM 750W 80+ Gold ATX 3.1 Fully Modular (Retail)
FSP ADVAN GM 750W PSU: 80+ Gold, ATX 3.1, fully modular, 12V-2x6 PCIe 5.1, HYB 120mm fan, ECO zero-RPM mode, Japanese caps, single +12V rail. 10yr warranty.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 700 - 799 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus Gold Cybenetics Gold |
| PSU (Power Supplies) - Color | Black |
| PSU (Power Supplies) - Modularity | Fully modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 1x 12V-2x6 2x 8/6 pins |
| PSU (Power Supplies) - Length | Up to 140 mm |
| PSU (Power Supplies) - EPS CPU Connectors | 2x 4+4pin EPS/ATX12V |
ATX 3.1 Compliant Powerhouse
The FSP ADVAN GM 750W fully modular PSU meets Intel ATX 3.1 standards, supporting up to 200% power excursions and featuring the new PCIe 12V-2x6 connector for next-gen GPUs like NVIDIA RTX 40/50 series. Ideal for high-performance PCs with power-hungry CPUs and GPUs.
Premium Efficiency & Cooling
80 PLUS Gold and Cybenetics Gold certified for ≥90% efficiency. LLC resonant topology with synchronous rectification ensures stable voltage. 120mm HYB bearing fan with ECO switch enables zero-RPM silent mode below 40% load. 105°C Japanese capacitors for reliability.
- Fully modular black embossed cables for clean builds
- Single +12V rail: 62.5A / 750W
- 2x EPS 4+4pin CPU, 1x 12V-2x6 + 2x PCIe 6+2pin GPU
- Active PFC, full protections: OVP/OCP/OPP/OTP/SCP/UVP/SIP/NLO
- 10-year warranty
| Total power | 750 W |
| AC input voltage | 100 - 240 V |
| Input current | 5 A |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 750 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 62.5 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 90% |
| Power protection features | No load operation, Over current, Over power, Over voltage, Short circuit, Surge & inrush protection (SIP), Under voltage |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 60 cm |
| Number of SATA power connectors | 4 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| PCI Express power connectors (6+2 pin) | 2 |
| PCI Express power connectors (12V-2x6) | 1 |
| PCI Express power cable length | 70 cm |
| CPU power connector (4+4 pin) | 2 |
| CPU power cable length | 70 cm |
| Cabling type | Fully-Modular |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| Bearing technology | HYB |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
| Warranty | 10 Years |
